Hikvision HiLook NVR-104H-D/4P 4 channel NVR with 4 port POE (4MP Max)
SKU: NVR-104H-D/4PCopied!
4-ch Mini 1U 4 PoE NVR H.265+/H.265/H.264+/H.264 video compression Up to 40 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth Up to 4-ch network camera inputs Up to 4-ch 1080p decoding capability HDMI and VGA simultaneous output
Out of Stock
Currently unavailable
Currently Unavailable
This item is out of stock. Check back later!
Product Description
The NVR-104H-D/4P is a 4-channel Mini 1U NVR with a built-in 4-port PoE switch, spec'd for straightforward camera-and-recorder deployments without a separate PoE injector or switch on the install.
Key specs
- Channels: 4-ch network camera inputs, full-channel recording at up to 4MP
- PoE: 4 independent 100 Mbps built-in switch interfaces (self-powered camera runs, no external PoE hardware needed)
- Bandwidth: up to 40 Mbps incoming / 60 Mbps outgoing
- Compression: H.265+/H.265/H.264+/H.264
- Decoding: up to 4-ch at 1080p
- Output: HDMI and VGA simultaneous, both at 1080p
- Playback: 1-ch at 4MP or 2-ch at 1080p simultaneously
- Storage: 1x SATA HDD bay, up to 6TB
- Network: 100 Mbps Ethernet uplink, Hik-Connect for remote management
- Analytics: line crossing and intrusion detection, smart search for faster playback review
Compatibility note
Connects to third-party network cameras as well as Hikvision/HiLook models, so it can be dropped into mixed-vendor jobs — check onvif/feature parity with non-Hikvision cameras before relying on smart functions.
Note: this unit is currently out of stock.
Technical Specifications
Frequently Asked Questions
Does the NVR-104H-D/4P need a separate PoE switch for cameras?
No — it has 4 independent 100 Mbps built-in switch interfaces providing PoE directly to connected cameras.
What resolution can this NVR record and play back?
Full-channel recording is supported at up to 4MP. Playback is 1-ch at 4MP or 2-ch at 1080p simultaneously.
How much storage can be fitted?
One SATA hard disk can be connected, with support for up to 6TB capacity.
Will it work with non-Hikvision cameras?
Yes, the source confirms it is connectable to third-party network cameras, with up to 4 cameras supported in total.
