Product Description
DS-7604NXI-K1/4P is Hikvision's 4-channel, 4-port PoE 1U NVR from the K Series AcuSense line — a common spec for small-site and residential IP installs where a single-bay recorder with built-in PoE budget covers the cabling.
Key specs
- Channels: 4x IP inputs, all via integrated PoE — no separate switch needed for camera power/data
- Decoding: 1-ch@12MP, 2-ch@8MP, 5-ch@4MP, or 10-ch@1080p
- Incoming bandwidth: up to 40 Mbps
- Compression: H.265+/H.265/H.264+/H.264
- Storage: 1x SATA, drives up to 10TB
- Video out: HDMI up to 4K, VGA up to Full HD, simultaneous or independent output
- Network: dedicated LAN port plus the 4 PoE interfaces
- Remote access: Hik-Connect, ONVIF-compatible platforms
AcuSense on this model adds human/vehicle classification at the recorder, cutting false triggers from animals, foliage or weather — useful where reviewing footage manually isn't feasible. Facial capture and smart search speed up post-event review.
Cross-reference / part numbers
Also catalogued as DS-7604NI-K1/4P, DS-7604NI-K1/4P-(D), and the corresponding NO-HDD variants (DS-7604NXI-K1/4P-NO-HDD, DS-7604NI-K1/4P-NO-HDD, DS-7604NI-K1/4P-(D)-NO-HDD) — useful when cross-checking older quotes or supplier listings against this SKU.
Single SATA bay caps this unit at one drive, so plan capacity against the 10TB ceiling before scoping a job with heavy retention requirements.
Specifications
- Model
- DS-7604NXI-K1/4P
- Series
- K-Series
- Channels
- 4-CH
- Max Resolution
- 12MP
- Built-in PoE Ports
- 4 PoE
- PoE Budget (Total)
- ≤ 50 W
- Incoming Bandwidth
- 40 Mbps
- Outgoing Bandwidth
- 80 Mbps
- Video Compression
- H.265+, H.265, H.264+, H.264
- Recording Resolution
- 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Frame Rate
- 30fps
- Decoding Capability
- 1×12MP / 2×8MP / 4×4MP / 8×1080p
- HDMI Output
- 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- HDMI/VGA Independent
- Independent
- Max Total Storage
- 10 TB
- eSATA Port
- No
- AcuSense
- Yes
- DeepinMind / AI
- No
- Human & Vehicle Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- Yes
- Perimeter Protection
- Yes
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- False Alarm Filtering
- Yes
Technical Specifications
Frequently Asked Questions
How many PoE ports does the DS-7604NXI-K1/4P have?
It has 4 integrated PoE interfaces, one per channel, allowing direct camera connection and power without a separate switch.
What's the maximum camera resolution this NVR supports?
Decoding capacity tops out at 1-ch@12MP, or alternatively 2-ch@8MP, 5-ch@4MP, or 10-ch@1080p.
How much storage can I fit?
There's a single SATA interface supporting one hard drive up to 10TB.
Is DS-7604NI-K1/4P the same unit as DS-7604NXI-K1/4P?
Yes — DS-7604NI-K1/4P and DS-7604NI-K1/4P-(D) are listed as the same product under alternate part numbers, including their NO-HDD variants.
