What's in the box
Full parts list with quantities. Tap a line for its full spec.
8-camera kit · ~17 days recording · IP cameras — check the listed power equipment and cabling.
Recorder capacity
8 included cameras use 8 of the recorder’s 8 channels. All stated channels are occupied. A larger system needs a recorder with additional capacity.
Recording storage
6TB storage is included. Estimated recording time: about 17 days with continuous H.265 recording. The estimate uses 2 Mbps per camera up to 2MP, 4 Mbps up to 5MP and 8 Mbps above 5MP, summed for mixed camera models. Actual retention depends on settings, scene activity and usable drive capacity; motion-only recording varies with activity.
Before installation
Check the component list below for included cables, power supplies and mounting accessories. Choose cable lengths and camera positions for your layout; camera count alone does not establish coverage. Confirm lens field of view, lighting and weather protection for each position.
The recorder
1× PROLUX PXN-2108HS-8P-4K ,NVR 8 Channel 1U 8PoE 4K&H.265 Lite Network Video Recorder, Up to 2ch@4...
Records every channel and runs the app
The cameras
8× 5MP AI IP Dome Camera PoE Face Detection IR Night Vision 256GB SD ONVIF IP67
The units that go on the wall
The hard drive
1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Footage storage
The cable
8× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
Camera-to-recorder runs
Different cameras, a bigger drive or longer runs? Open this kit in the builder and swap any part — each change is re-checked against the rest, so you can't spec parts that don't work together.
Product Description
A complete 8-channel IP (PoE) CCTV kit built on the Prolux PXN-2108HS-8P-4K + 8× LWA28PW-C3. 8 cameras at 5MP — sized for a shop or small office. The included 6TB surveillance hard drive holds about 17 days of continuous recording — the estimate assumes recording all 8 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 8× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable. In the box: 1× PROLUX PXN-2108HS-8P-4K ,NVR 8 Channel 1U 8PoE 4K&H.265 Lite Network Video Recorder, Up to 2ch@4...; 8× 5MP AI IP Dome Camera PoE Face Detection IR Night Vision 256GB SD ONVIF IP67; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 8× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable.
Specifications
- System type
- IP (network)
- Built on
- Prolux PXN-2108HS-8P-4K + 8× LWA28PW-C3
- Recorder
- 8-channel PROLUX PXN-2108HS-8P-4K ,NVR 8 Channel 1U 8PoE 4K&H.265 Lite Network Video Recorder, Up to 2ch@4...
- Cameras included
- 8× 5MP AI IP Dome Camera PoE Face Detection IR Night Vision 256GB SD ONVIF IP67
- Camera resolution
- 5MP
- Storage
- 6TB surveillance HDD — about 17 days of footage, recording all 8 cameras continuously at high quality (H.265)
- Cables & PSU included
- 8× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
- What's in the box
- 1× PROLUX PXN-2108HS-8P-4K ,NVR 8 Channel 1U 8PoE 4K&H.265 Lite Network Video Recorder, Up to 2ch@4...; 8× 5MP AI IP Dome Camera PoE Face Detection IR Night Vision 256GB SD ONVIF IP67; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 8× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
