Product Description
The PXN-2108HS-8P-4K is an 8-channel 1U NVR with 8 built-in PoE ports (IEEE 802.3at/af), giving installers a single-box IP recording solution with no separate switch needed on standard runs.
Bandwidth and decoding
Incoming bandwidth tops out at 80Mbps, with a total PoE budget of 80W (max 25.5W per port). Preview and playback go up to 8MP resolution, but decode capacity is the figure to plan around: 1ch@8MP/30fps or 4ch@1080P/30fps — this is a 4K-lite recorder, not a full multi-channel 4K unit, so it suits mixed-resolution sites rather than all-8MP deployments.
Storage and outputs
- Single SATA III bay, up to 6TB per HDD (spec table also lists up to 10TB — check drive compatibility before quoting a capacity to a client)
- HDMI output to 3840×2160, VGA to 1920×1080
- Simultaneous HDMI/VGA operation for dual-monitor setups
- 1/4/8/9 multi-screen layouts
Compression and network
H.265/H.264 recording at 16Kbps–20Mbps per channel, with schedule/MD/manual recording modes and configurable pre/post-record windows. Network side runs a single 10/100Mbps RJ-45, ONVIF 2.4/SDK/CGI for third-party integration (Axis, Bosch, Panasonic, Pelco, Sony and others listed), and supports up to 128 concurrent users.
Physically it's a compact 1U chassis (260×224.9×47.6mm), rated for -10°C to +55°C operation, with CE, FCC and UL certification.
No alarm I/O, RS232/RS485 or eSATA on this model — budget for external alarm handling if the job needs it.
Specifications
- Brand
- PROLUX
- Channels
- 8
- Colour
- Black
- Max Resolution
- 8 MP
- Storage Capacity
- Up to 10 TB
- Video Compression
- H.265/H.264
- Video Outputs
- HDMI, VGA
Technical Specifications
Frequently Asked Questions
How many PoE ports does the PXN-2108HS-8P-4K have and what's the total power budget?
It has 8 PoE ports (IEEE802.3at/af), with a maximum of 25.5W per single port and 80W total across all ports.
Can this NVR record 8 channels at 8MP simultaneously?
No — decoding capacity is limited to 1 channel at 8MP/30fps or 4 channels at 1080P/30fps, so plan resolution mix accordingly across the 8 channels.
What's the maximum hard drive capacity supported?
The spec table lists one SATA III bay supporting up to 6TB per HDD (a separate storage entry also cites up to 10TB), so confirm drive compatibility before committing to a capacity.
Does the PXN-2108HS-8P-4K support third-party IP cameras?
Yes, via ONVIF 2.4, SDK and CGI, with listed third-party compatibility including Axis, Bosch, Panasonic, Pelco, Sony and others.
