Product Description
XVR-3108HS-5MP-LITE — 8-channel Penta-brid DVR
The XVR-3108HS-5MP-LITE takes 8 analogue channels across HDCVI, AHD, TVI and CVBS, plus IP inputs, on one recorder. That makes it a practical swap-in for mixed-generation sites where you're bridging legacy coax cameras with newer IP additions without a full rip-and-replace.
Key specs
- Channels: 8, with synchronous 8-channel playback
- Max resolution: 5MP per channel
- Video inputs: HDCVI, AHD, TVI, CVBS, IP
- Compression: H.265+
- Storage: 1× SATA, up to 10TB HDD (not included)
- Network: 1× RJ-45, 10/100/1000Mbps
- USB: 2× USB 2.0
- Audio: 1× RCA input
- Power: 12V DC
- Operating range: -10°C to +55°C
- Dimensions: 315 × 45 × 240 mm; 1.2kg
Also listed as
Some catalogue entries carry this unit under XVR-3108HS-5MP-LITE-NO-HDD or XVR-3108HS-5MP-LITE+NO-HDD — same hardware, no drive fitted, so confirm which SKU you're quoting against before ordering a HDD separately.
Fitting notes
Single SATA bay caps you at one drive regardless of channel count, so plan storage budget per site before spec'ing this over a multi-bay alternative. The single RJ-45 port handles both remote viewing and IP channel integration — no separate PoE switch capacity is described here, so IP cameras added via this recorder will need power from elsewhere.
Specifications
- Brand
- Unbranded
- Channels
- 8
- Colour
- Black
- Max Resolution
- 5 MP
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Compression
- H.265/H.265+
- Video Inputs
- TVI/AHD/CVI/CVBS/IP
- Video Outputs
- HDMI, VGA
Technical Specifications
Frequently Asked Questions
What camera types can I connect to the XVR-3108HS-5MP-LITE?
It accepts HDCVI, AHD, TVI and CVBS analogue cameras alongside IP cameras, all on the same 8-channel unit.
What's the maximum HDD it supports?
One SATA interface supporting a hard drive up to 10TB, purchased separately.
Is this the same unit as the NO-HDD listings?
Yes — XVR-3108HS-5MP-LITE-NO-HDD and XVR-3108HS-5MP-LITE+NO-HDD refer to the same DVR without a drive fitted.
What's the maximum recording resolution per channel?
Up to 5MP per channel, with H.265+ compression for storage efficiency.
