Product Description
XVR-3116HS-5MP-LITE is a 16-channel hybrid DVR taking HDCVI, AHD, TVI, CVBS and IP inputs on the same chassis — useful for phased upgrades where analog runs stay in place while cameras are swapped for IP over time.
Key specs
- Compression: H.265+/H.265 dual-stream, with full-channel AI-Coding for reduced bitrate at equivalent quality
- Analog inputs: HDCVI/AHD/TVI/CVBS, up to 8 channels of analog SMD Plus (smart motion detection) video stream
- IP inputs: up to 12 channels, each up to 5MP resolution
- Incoming bandwidth: 64 Mbps maximum
- Total capacity: 16 channels across mixed analog/IP inputs
Why it matters on a job
The hybrid input set means a single recorder can service a site with legacy coax cameras and newer IP cameras concurrently — no need to run a separate NVR for IP additions. SMD Plus on up to 8 analog channels gives smart motion filtering on those inputs without requiring an IP swap.
Bandwidth is capped at 64 Mbps total incoming, so channel allocation across the 12 IP inputs should be planned against that ceiling when specifying camera resolutions and frame rates for a design.
Outputs include HDMI and VGA for monitor connection, with remote viewing and playback supported via a compatible client device. Storage is via internal HDD, with support for external storage devices for archiving.
Specifications
- Brand
- Unbranded
- Channels
- 16
- Colour
- Black
- Max Resolution
- 5 MP
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Compression
- H.265/H.265+
- Video Inputs
- TVI/AHD/CVI/CVBS/IP
- Video Outputs
- HDMI, VGA
Frequently Asked Questions
How many IP cameras can the XVR-3116HS-5MP-LITE take alongside analog inputs?
Up to 12 IP channels, each up to 5MP, in addition to the analog HDCVI/AHD/TVI/CVBS inputs, within a total 16-channel capacity and a 64 Mbps incoming bandwidth ceiling.
Does this DVR support smart motion detection on analog channels?
Yes — up to 8 analog channels support SMD Plus (smart motion detection) video streaming.
What video compression does this DVR use?
H.265+ and H.265 dual-stream compression, with full-channel AI-Coding supported across channels.
What monitor outputs are available?
The DVR provides both HDMI and VGA outputs for connecting to displays.
