Product Description
Key specs
The XVR5108H-4KL-X-8P is an 8-channel Penta-brid recorder covering HDCVI, AHD, TVI, CVBS, and IP camera inputs on a single unit.
- PoC: built-in Power over Coax, up to 8 PoC camera inputs, 48W total PoC power budget
- Recording resolution: up to 4K on analogue inputs, up to 8MP on IP inputs
- Hybrid IP expansion: up to 12 IP channels in 8+4 hybrid mode
- Compression: H.265+ for reduced storage/bandwidth load
- Video outputs: HDMI up to 4K, simultaneous VGA output
- Storage: 1 SATA HDD bay, up to 10TB capacity
- Search: Smart Search and Intelligent Video System support
Why it matters on install
Running PoC cameras off this recorder means power and video share the coax run, cutting the cable count on retrofit jobs where separate power runs aren't practical. The 48W budget across 8 PoC inputs is the figure to check against camera draw before quoting a job.
Compatibility note
This SKU is also listed under DH-XVR5108H-4KL-X-8P-NO-HDD and DH-XVR5108H-4KL-X-8P+NO-HDD — same hardware, no bundled hard drive, so factor in a separate SATA HDD purchase up to 10TB.
Mixed analogue/IP estates suit this unit well: HDCVI, AHD, TVI and CVBS cameras run alongside IP cameras on the same recorder, with hybrid mode extending IP capacity beyond the base 8 analogue channels when a site needs it.
Specifications
- Brand
- Dahua
- Model
- XVR5108H-4KL-X-8P
- Series
- WizSense / XVR Series
- Channels
- 8
- Max Resolution
- 8MP (4K)
- Colour
- Black
- Video Compression
- H.265/H.264/H.265+/H.264+
- Frame Rate
- 7 fps @ 4K / 15 fps @ 4MP / 30 fps @ 1080p
- App Compatibility
- DMSS
- Camera Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any ONVIF-conformant IP camera.
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Inputs
- TVI/AHD/CVI/CVBS/IP
- Video Outputs
- HDMI, VGA
- Human & Vehicle Detection
- Yes
- Face Detection
- No
- Face Recognition
- No
Technical Specifications
Frequently Asked Questions
How many PoC cameras can this DVR power?
It supports up to 8 PoC camera inputs with a total PoC power budget of 48W.
Can I add IP cameras alongside the analogue channels?
Yes, hybrid mode extends the unit to up to 12 IP camera inputs (8+4 hybrid mode).
What's the maximum recording resolution?
Up to 4K on analogue inputs and up to 8MP on IP camera inputs.
How much storage does it support?
One SATA HDD interface supporting up to 10TB capacity.
Does it come with a hard drive?
The base SKU and its NO-HDD variants (DH-XVR5108H-4KL-X-8P-NO-HDD / +NO-HDD) are the same hardware without a bundled HDD.
