Product Description
The XVR-3108AD-4MP is an 8-channel hybrid DVR built for mixed analogue/IP CCTV jobs. It takes TVI, AHD, CVI, CVBS and IP cameras on the same recorder, so upgrade jobs on legacy analogue runs don't require ripping out existing cameras.
Key specs
- 8 channels, hybrid mode for TVI/AHD/CVI/CVBS plus IP camera input
- Recording resolution up to 4MP
- H.264/H.265 compression for storage efficiency
- HDMI and VGA outputs for local monitor connection
- 1 SATA HDD supported for internal storage
- USB ports for backup and firmware updates
- Remote viewing via mobile app and network access
Aliases and part numbers
This SKU is also listed as XVR-3108AD-4MP-NO-HDD, XVR-3104AD-4MP and XVR-3104AD-4MP+NO-HDD. These are alternate listing references for the same product line; the source data doesn't specify how the alias models differ in spec from the base part number, so check with your distributor if channel count or drive fitment matters for a specific job.
On-site notes
Single SATA HDD support means storage sizing is a one-drive decision — plan capacity around the resolution and channel count you're actually recording, not just what the DVR can technically accept. HDMI and VGA both being present means you can run a local monitor without adapters, which is handy on install day when you just need to confirm picture before closing up the enclosure.
Specifications
- Brand
- Generic
- Model
- XVR-3108AD-4MP
- Channels
- 8-CH
- Max Resolution
- 4 MP
- Colour
- Black
- Built-in PoE Ports
- 10 PoE
- Video Compression
- H.265
- Recording Resolution
- 4MP
- Max Output Resolution
- 4MP
- Camera Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any ONVIF-conformant IP camera.
- Storage Capacity
- Up to 10 TB
- Technology
- XVR
- Video Outputs
- HDMI, VGA
Technical Specifications
Frequently Asked Questions
What camera types does the XVR-3108AD-4MP support?
It supports TVI, AHD, CVI and CVBS analogue cameras plus IP cameras via hybrid mode.
What is the maximum recording resolution?
The recorder supports recording resolution up to 4MP.
How many hard drives can I fit?
The DVR supports 1 SATA HDD for internal storage.
Do the alias part numbers differ in spec from the base model?
The source listing only shows XVR-3108AD-4MP-NO-HDD, XVR-3104AD-4MP and XVR-3104AD-4MP+NO-HDD as alternate references; no separate spec differences are given.
