Product Description
LWA28PW-C3 is a 5MP AI IP dome, 2592×1944, built for spec-driven installs where analytics and PoE budgeting matter more than marketing copy.
Key specs
- Sensor/lens: 5MP, 2592×1944, 2.8mm fixed wide-angle lens
- IR/low-light: up to 30m IR range, 0.003 lux minimum illumination
- Analytics: face detection, people/vehicle recognition, licence plate detection, perimeter intrusion, heat mapping
- Compression: H.265/H.264, triple-stream
- Storage: onboard 256GB micro SD slot for standalone edge recording without an NVR
- Power: single-cable PoE
- Housing: IP67/IK10-rated metal casing
- Operating range: -35°C to +60°C
- Standards: ONVIF Profile S/G/T/M
For integrators, the ONVIF S/G/T/M profile support is the headline: it's what lets this unit slot into third-party VMS platforms without proprietary SDK work. The triple-stream H.265/H.264 setup gives you room to run a low-bitrate substream to the NVR while keeping a higher-quality stream on the SD card for local evidence retrieval — useful where bandwidth on the PoE switch is already tight.
IP67 plus IK10 covers both weatherproofing and impact resistance, so it's rated for external mounting on exposed elevations as well as higher-risk indoor locations. The -35°C to +60°C operating window extends the deployment envelope into cold-store and exposed rooftop plant applications where standard dome cameras spec out at a narrower range.
Specifications
- Protection Rating
- IP67, IK10
- Capacity
- 256GB
- Resolution
- 5MP
Frequently Asked Questions
Does this camera support ONVIF for third-party VMS integration?
Yes — it supports ONVIF Profile S/G/T/M, covering streaming, analytics metadata, PTZ (where applicable) and event handling for third-party platforms.
Can it record without an NVR?
Yes, it has an onboard 256GB micro SD slot enabling standalone edge recording independent of an NVR.
What's the IR range and low-light performance?
IR night vision reaches up to 30 metres with a minimum illumination of 0.003 lux.
Is the housing rated for outdoor and high-impact locations?
Yes — the metal casing is IP67 and IK10 rated, covering both weatherproofing and impact resistance.
