Product Description
Overview
PXC-612C4W-A-POC is a 4MP PoC eyeball camera: video, power and audio all run over one coaxial cable, no local PSU needed at the camera end.
Key specs
- Resolution: 2560 × 1440 (4MP) over coax
- Lens: fixed 2.8mm, wide-angle
- Power/video: PoC (Power over Coax) — single cable run
- IR range: up to 50m illumination distance
- Day/Night: automatic IR cut filter, True Day/Night switching
- Audio: built-in microphone, transmitted over coax to a compatible PoC DVR
- Housing: eyeball turret, indoor/outdoor installation
- DVR compatibility: Hikvision and HiLook PoC platforms
Deployment notes
PoC removes the need for a separate power cable to each camera position — useful on retrofit jobs where coax is already in place and re-cabling for mains power isn't practical. The camera pulls power from the PoC-enabled DVR over the same run that carries video, so confirm the recorder is PoC-capable before adding this camera to a spec: it's confirmed against Hikvision and HiLook PoC DVR platforms, not generic analogue-HD recorders.
Audio is over-coax only — it requires the paired DVR to decode and record it, so check the recorder's audio-over-coax support alongside PoC support when quoting a system.
The 2.8mm fixed lens suits entrance, corridor and perimeter coverage where a wide field of view is wanted over a long throw distance. Housing is rated for indoor and outdoor mounting positions.
Specifications
- Brand
- Prolux
- Camera Type
- Analog Camera
- Resolution
- 4MP
- Smart Hybrid Light
- IR Only
- IR Distance
- 50m
- Built-in Microphone
- Yes
- Connection Type
- Analogue
- IP Rating
- IP67
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
Technical Specifications
Frequently Asked Questions
Does this camera need a PoC-capable DVR?
Yes — it draws power over the coax cable itself, so the recorder must support PoC (confirmed with Hikvision and HiLook PoC DVR platforms).
What's the maximum resolution?
2560 × 1440 (4MP) delivered over the PoC coaxial connection.
How far does the infrared illumination reach?
Up to 50 metres, with automatic IR cut filter switching for True Day/Night operation.
Does the built-in microphone record to any DVR?
Audio is transmitted over coax and needs a compatible PoC DVR to capture it alongside the video.
