Product Description
Key specs
- Sensor/resolution: 1/3" progressive scan CMOS, 4MP (2560 × 1440)
- Lens: fixed 2.8mm, 98° horizontal FoV — no varifocal option on this SKU
- Illumination: Smart Hybrid Light (IR + white light), auto-switching, range up to 30m
- Compression: H.265+, H.265, H.264+, H.264
- Power: PoE (IEEE 802.3af) or 12V DC — single-cable install on any 802.3af-compliant switch/injector
- Audio: built-in mic and speaker, two-way audio
- Analytics: human/vehicle classification (on-camera, no external analytics box needed)
- Ingress: IP67
- Storage: onboard microSD, up to 512GB
For spec'ing a job: the 802.3af PoE draw keeps this within standard PoE budget calculations — no need to reserve PoE+ headroom on the switch port, which matters when stacking channel counts against an NVR's total PoE budget. The fixed 2.8mm/98° lens fixes the FoV at design stage — there's no on-site zoom adjustment, so confirm coverage distance before quoting.
Smart Hybrid Light switches between IR and white-light illumination automatically based on scene/motion triggers rather than requiring a separate white-light floodlight circuit, which simplifies wiring on turret deployments at entrances or perimeter runs.
Integrates with Hikvision NVRs and ONVIF-compliant VMS platforms — check your existing NVR's ONVIF profile support and available PoE ports before adding to an existing multi-camera system.
Specifications
- Model
- DS-2CD1343G2-LIUF/SL
- Resolution
- 4MP
- Housing Material
- Metal & Plastic
- Night Vision
- Yes
- Low Light
- Yes
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- Auto
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Two-Way Audio
- Yes
- Motion Detection
- Smart
- Human Detection
- Yes
- Vehicle Detection
- Yes
- Line Crossing
- No
- Intrusion Detection
- No
- Face Detection
- No
- Face Recognition
- No
- False Alarm Filtering
- Yes
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- IEEE 802.3af, Class 3
- Power Supply
- 12V DC ±25% PoE IEEE 802.3af
- Max Power
- 9.5W max
- IP Rating
- IP67
Technical Specifications
Frequently Asked Questions
What PoE standard does the DS-2CD1343G2-LIUF/SL require?
It runs on standard IEEE 802.3af PoE, or 12V DC where PoE isn't available — no PoE+ budget needed on the switch port for this camera.
Can the lens angle be adjusted on site?
No — this SKU has a fixed 2.8mm lens giving a 98° horizontal field of view. There's no varifocal or zoom adjustment, so confirm coverage requirements before installation.
Does it support onboard recording without an NVR?
Yes, it takes onboard microSD storage up to 512GB, in addition to integrating with Hikvision NVRs and ONVIF-compatible VMS platforms.
What analytics does the camera run on-board?
It supports human and vehicle detection classification directly on the camera, alongside Smart Hybrid Light IR/white-light illumination up to 30m.
