Product Description
DS-2CD2T47G2H-LISU/SL — spec sheet for the install
4MP bullet from Hikvision's PRO line built for perimeter jobs where deterrence and low-light identification both matter. 1/1.8" progressive scan CMOS, 2688 × 1520 output at up to 25fps through the fixed 2.8mm F1.0 lens (104° horizontal FoV).
Illumination and imaging
Smart Hybrid Light switches automatically between IR and white light, extending coverage to 60m. ColorVu keeps the feed in full colour through the night rather than dropping to mono IR. 130dB true WDR handles doorway/car-park glare and backlit entrances without clipping highlights or crushing shadow detail.
Analytics and deterrence
AcuSense runs human/vehicle classification on-camera for line crossing, intrusion, region entry/exit — filters out the leaf and cat triggers before they hit your VMS. Face capture is supported. For active response the unit carries a built-in strobe and siren, plus mic and speaker for two-way audio challenge.
Power and storage
PSU flexibility: PoE IEEE 802.3af or 12V DC, so it drops onto any 802.3af NVR/switch budget without a separate injector, or runs on local DC where PoE isn't available. Onboard storage to 512GB microSD for edge recording independent of the NVR. H.265+ keeps bandwidth and archive size down on multi-camera runs.
Build
Full metal housing, IP67-rated — spec it for exposed elevations, gable ends, and unsheltered perimeter runs.
Specifications
- Model
- DS-2CD2T47G2H-LISU/SL
- Resolution
- 4MP
- Camera Style
- Bullet
- IR Distance
- 60m
- Low Light
- Yes
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- Auto
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Two-Way Audio
- Yes
- Motion Detection
- Smart
- Human Detection
- Yes
- Vehicle Detection
- Yes
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- Yes
- False Alarm Filtering
- No
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- 802.3af
- Power Supply
- 12V DC PoE IEEE 802.3af
- Max Power
- 10.5W max
- IP Rating
- IP67
Technical Specifications
Frequently Asked Questions
What PoE standard does the DS-2CD2T47G2H-LISU/SL need?
It runs on PoE IEEE 802.3af, or alternatively 12V DC where PoE isn't available on the run.
How far does the Smart Hybrid Light illuminate?
Up to 60 metres, with the camera automatically switching between IR and white light.
What's the maximum storage this camera supports on-board?
A microSD card up to 512GB for local edge recording.
Does this camera do human/vehicle detection?
Yes — AcuSense provides human and vehicle classification with false-alarm filtering for line crossing, intrusion and region entry/exit events.
Is the housing rated for exposed outdoor mounting?
Yes, it's a full metal IP67-rated housing suited to unsheltered perimeter positions.
