Product Description
DS-2CD2H45FWD-IZS-2.8-12MM is a 4MP motorised varifocal turret, PoE-powered, built for spec-driven installs where lens flexibility and low-light performance matter more than headline resolution.
Key specs
- Sensor: 1/2.5" progressive scan CMOS, 2688×1520 at up to 30fps
- Lens: motorised 2.8–12mm varifocal, remote zoom/focus, 114° wide to 32° tele field of view
- Low light: Powered-by-DarkFighter, minimum illumination down to 0.008 lux, IR range up to 30m
- WDR: 120dB true WDR for backlit doorways, loading bays, yard entrances
- Analytics: line crossing, intrusion, unattended baggage, object removal, face detection
- Storage: onboard microSD, up to 128GB, no NVR dependency for edge recording
- Power: IEEE 802.3af PoE or 12V DC — confirm PoE budget per port on multi-camera runs
- Housing: IP66 weatherproof, IK10 vandal-resistant metal turret body
The remote zoom/focus motor removes the need to reposition the camera on site once mounted — set field of view from the VMS or camera menu after fixing. Useful on jobs where the exact coverage angle isn't confirmed until commissioning.
At IEEE 802.3af, this sits within standard PoE switch port budgets; check total draw where IR is active continuously alongside other loads on the same switch. IP66/IK10 rating covers external mounting and impact exposure without added housings.
No cross-generation part-number equivalence is stated for this SKU in current documentation — verify against your own compatibility matrix before substituting into an existing Hikvision estate.
Specifications
- Brand
- Hikvision
- Model
- DS-2CD2H45FWD-IZS
- Resolution
- 4MP
- Camera Style
- Motorized Varifocal Turret
- Use Case
- Indoor / Outdoor, vandal-resistant, commercial surveillance
- Optical Zoom
- 4.3× optical zoom
- Low Light
- Yes
- ColorVu
- No
- White Light
- No
- Day/Night Mode
- Auto
- Built-in Microphone
- No
- Built-in Speaker
- No
- Two-Way Audio
- No
- Motion Detection
- Basic
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- No
- False Alarm Filtering
- No
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- 802.3af
- Power Supply
- 12V DC
- Max Power
- 11W max (DC) 12.5W max (PoE)
- IP Rating
- IP66
Technical Specifications
Frequently Asked Questions
What PoE standard does the DS-2CD2H45FWD-IZS-2.8-12MM require?
It runs on IEEE 802.3af PoE or 12V DC. Factor continuous IR draw into your switch's total PoE budget on multi-camera runs.
Can the lens be adjusted after mounting?
Yes — the 2.8–12mm lens is motorised for remote zoom and focus, so field of view (114° wide to 32° tele) can be set from the camera menu or VMS without repositioning the unit.
What's the local storage capacity?
The camera has a built-in microSD slot supporting up to 128GB, allowing onboard recording independent of an NVR.
Is it rated for outdoor and high-impact locations?
Yes — the metal turret housing is IP66 weatherproof and IK10 vandal-resistant, suitable for external and exposed mounting positions.
