Product Description
DS-2CD2H83G0-IZS-2.8-12MM is an 8MP (3840×2160) motorized varifocal turret, IP66/IK10, powered over standard IEEE 802.3af PoE — spec it where lens reach or vandal rating rules out a fixed-lens turret.
Key specs for the job sheet
- Sensor/resolution: 1/2.5" progressive scan CMOS, 3840×2160 (8MP)
- Lens: motorized 2.8–12mm varifocal, remote zoom/focus — FOV 105° (wide) to 34.5° (tele), per the datasheet lens table
- IR range: up to 30m illumination
- WDR: 120 dB true WDR for backlit entrances/yards
- Compression: H.265+ (bandwidth/storage saving on multi-channel NVR runs)
- Storage: onboard microSD, up to 128GB
- Analytics: line crossing, intrusion detection, face detection
- Power: PoE, IEEE 802.3af
- Housing: IP66 weatherproof, IK10 vandal-resistant metal
Deployment notes
The motorized 2.8–12mm lens lets you set field of view from the NVR/config tool after mounting — useful on turret installs where re-racking the camera to adjust angle isn't practical. Onboard analytics (line crossing, intrusion, face detection) run at the edge, so alarm rules can be configured without dedicating NVR channel-level VCA licensing, where your platform supports it.
Confirm PSU/PoE injector output against total run length and any other PoE loads on the switch port before quoting — 802.3af budget is fixed regardless of camera feature set.
Also listed under MPN DS-2CD2H83G0-IZS-2.8mm-12mm-W — same unit, alternate part-number formatting seen across Hikvision distribution.
Specifications
- Model
- DS-2CD2H83G0-IZS
- Resolution
- 8MP (4K)
- Camera Style
- Motorized Varifocal Turret
- Lens / Field of View
- Motorized varifocal 2.8–12mm lens
- Optical Zoom
- 4.3× optical zoom
- Smart Hybrid Light
- IR Only
- Low Light
- Yes
- ColorVu
- No
- White Light
- No
- Day/Night Mode
- Auto
- Built-in Microphone
- No
- Built-in Speaker
- No
- Two-Way Audio
- No
- Motion Detection
- Basic
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- No
- False Alarm Filtering
- No
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- 802.3af
- Power Supply
- 12V DC ±25% PoE IEEE 802.3af
- Max Power
- 11W max (DC) 12.5W max (PoE)
- IP Rating
- IP67
Technical Specifications
Frequently Asked Questions
What PoE standard does the DS-2CD2H83G0-IZS use?
It runs on standard IEEE 802.3af PoE, so power and data run over a single Ethernet cable from any 802.3af-compliant PoE switch or injector.
Can the lens angle be adjusted after installation?
Yes — the 2.8-12mm lens is motorized varifocal with remote zoom and focus, giving a field of view from 105° at wide angle down to 34.5° at telephoto without repositioning the camera.
What's the maximum IR range and storage capacity?
Infrared illumination reaches up to 30 metres, and the built-in microSD slot supports local recording up to 128GB.
Is this camera rated for outdoor and vandal-prone locations?
Yes — the housing is IP66 weatherproof and IK10 vandal-resistant, suitable for exposed perimeter or commercial installs.
