Product Description
DS-2CD2387G3-LIS2UY/SL — spec summary for spec'ing on a job
8MP (3840×2160), 1/1.8" progressive scan CMOS with F1.0 lens — the wide aperture is the point: it pulls in far more light per pixel than a standard f/1.6–f/2.0 lens, which is what lets ColorVu 3.0 hold colour at night rather than dropping to mono IR.
Illumination and optics
- Smart Hybrid Light: automatic switching between IR and white light, illumination range up to 30m.
- Fixed 2.8mm lens, 108.8° horizontal field of view — a wide-angle field, so plan for entrances and perimeter runs rather than long chokepoint corridors.
- IP67-rated anti-corrosion metal housing for external mounting.
Audio and deterrence
Dual built-in microphones and a speaker give two-way audio on the same unit — no separate audio module to feed on the run. Active deterrence (strobe + audible alarm) fires on detection events, useful where a monitored response is wanted before an incident escalates.
Analytics and integration
- Deep-learning human/vehicle classification, plus line-crossing and intrusion detection.
- Onboard storage to 512GB via microSD — a useful edge buffer if the NVR link drops.
- Powers over PoE (IEEE 802.3at) or 12V DC, giving flexibility on runs where PoE budget is tight.
- Integrates with Hikvision and ONVIF-compliant NVR platforms.
Spec against your PoE budget table before adding to a multi-camera run — 802.3at draw is higher than 802.3af, and combined with IR/white-light load at night, cable length and switch port budget both need checking.
Specifications
- Model
- DS-2CD2387G3-LIS2UY/SL
- Resolution
- 8MP (4K)
- IR Distance
- 40m
- Low Light
- Yes
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- Auto
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Two-Way Audio
- Yes
- Motion Detection
- Smart
- Human Detection
- Yes
- Vehicle Detection
- Yes
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- No
- False Alarm Filtering
- Yes
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- 802.3af
- Power Supply
- 12V DC ±25% PoE IEEE 802.3at
- Max Power
- 15.5W max (DC) 17W max (PoE)
- IP Rating
- IP67
- Video Compression
- H.265+
Technical Specifications
Frequently Asked Questions
Does this camera need PoE, or can it run on a standard 12V supply?
It supports either PoE (IEEE 802.3at) or 12V DC, so it can be run on a PoE switch/NVR port or a separate 12V power feed.
What is the field of view with the fitted lens?
It has a fixed 2.8mm lens giving a 108.8° horizontal field of view, suited to wide entrance or perimeter coverage rather than narrow chokepoints.
How far does the illumination reach at night?
Smart Hybrid Light (IR and white light, switching automatically) illuminates up to 30 metres.
Can footage be stored on the camera itself, or only on an NVR?
It supports onboard storage up to 512GB via microSD, in addition to integrating with Hikvision and ONVIF-compatible NVR systems.
