DS-2CD1383G2-LIU: 8MP turret with dual illumination for spec-driven installs
The DS-2CD1383G2-LIU is an 8MP (3840×2160) fixed turret on a 1/2.7" progressive scan CMOS sensor, built for jobs needing high-res detail plus intelligent VCA on a standard PoE run.
Lens and field of view: fixed 2.8mm optic gives a 113° horizontal field of view — suited to entrances, forecourts and open perimeter runs rather than long throw.
Illumination: Smart Hybrid Light switches between IR and white light automatically depending on ambient conditions and detection events, with illumination coverage up to 30m — useful where colour identification at night matters as much as detection range.
Analytics: onboard human and vehicle classification filters out irrelevant motion (animals, foliage, weather) at the edge, cutting false triggers before they hit the NVR or VMS.
Audio: built-in microphone records synchronised audio alongside video for evidential purposes.
Compression: H.265+ reduces bitrate and storage draw versus older codecs — relevant when sizing NVR storage across multi-camera runs.
Power and integration
- PoE: IEEE 802.3af, or 12V DC where PoE isn't available — check switch/injector PoE budget before adding this to an existing run
- Housing: IP67-rated turret, indoor or outdoor
- Compatibility: integrates with Hikvision NVR systems and ONVIF-compatible VMS platforms
MPN: DS-2CD1383G2-LIU-2.8MM-W. Also listed as GR-DS-2CD1383G2-LIU-LN.
Specifications
- Model
- DS-2CD1383G2-LIU
- Resolution
- 8MP (4K)
- Housing Material
- Metal & Plastic
- Night Vision
- Yes
- Low Light
- Yes
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- Auto
- Built-in Microphone
- Yes
- Built-in Speaker
- No
- Two-Way Audio
- No
- Motion Detection
- Smart
- Human Detection
- Yes
- Vehicle Detection
- Yes
- Line Crossing
- No
- Intrusion Detection
- No
- Face Detection
- No
- Face Recognition
- No
- False Alarm Filtering
- Yes
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- IEEE 802.3af, Class 3
- Power Supply
- 12V DC ±25% PoE IEEE 802.3af
- Max Power
- 6.5W max
- IP Rating
- IP67
Technical Specifications
Frequently Asked Questions
Does the DS-2CD1383G2-LIU need a separate power supply, or does it run on PoE?
It runs on standard IEEE 802.3af PoE, or 12V DC where PoE isn't available — check your switch or injector's PoE budget before adding it to an existing run.
What illumination range does the Smart Hybrid Light give at night?
Up to 30m, with the camera automatically switching between IR and white light depending on ambient conditions and detection events.
Will this camera reduce false motion alerts from animals or moving foliage?
It supports onboard human and vehicle classification designed to filter out irrelevant motion before triggering an alarm.
Is the DS-2CD1383G2-LIU compatible with third-party NVRs or VMS?
It integrates with Hikvision NVR systems and is also ONVIF-compatible for third-party video management platforms.
