Product Description
Overview
The DS-2CE12UF3T-E is an 8MP 4K HD-TVI bullet camera built for coaxial installs where resolution matters more than a network upgrade. Maximum output is 3840 × 2160, giving installers detail suitable for perimeter lines, entrances, and industrial or commercial sites.
Key specs
- Resolution: 8MP / 4K, 3840 × 2160 max
- Lens options: 2.8mm, 3.6mm, 6mm fixed focal
- WDR: 130 dB true WDR for backlit scenes
- Noise reduction: 3D DNR for cleaner low-light frames
- White light distance: up to 40m for colour night imaging
- IR range: up to 80m for infrared night vision
- Housing: IP67-rated, dust and water resistant
- Output formats: HD-TVI, AHD, CVI, CVBS
Day/night operation
The camera switches automatically between colour daylight capture and IR-assisted monochrome at night via an IR cut filter, giving 24/7 usable footage without manual mode changes.
Compatibility note
Multi-format output (HD-TVI/AHD/CVI/CVBS) means this camera can drop into existing analogue DVR chains across brands, useful when upgrading a legacy coax run without swapping the whole recorder. Confirm the target DVR supports 8MP HD-TVI input before specifying, as older 4-channel recorders may cap at lower resolutions.
Lens variant (2.8mm/3.6mm/6mm) should be specified at order stage — field of view differs significantly between them on tight entrance shots versus wider perimeter coverage.
Specifications
- Image Sensor
- 8 MP CMOS
- Resolution
- 3840 (H) × 2160 (V)
- Frame Rate
- TVI: 8 MP @ 12.5 fps/15 fps, 3K @ 20 fps, 1080P @ 25 fps/30 fps
- Lens
- 2.8mm fixed focal lens
- Field of View
- 2.8 mm, horizontal FOV: 110°, vertical FOV: 59°, diagonal FOV: 131°
- Lens Mount
- M16
- Light Alarm
- Solid Light Alarm (White Light)
- Day & Night
- 24/7 Colour Imaging
- WDR (Wide Dynamic Range)
- ≥130 dB
- Angle Adjustment
- Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Day/Night Mode
- Colour
- White Balance
- Auto/Manual
- AE (Auto Exposure) Mode
- WDR;BLC;HLC;Global;HLS
- Motion Detection
- 4 programmable motion areas
- Noise Reduction
- 3D DNR/2D DNR
- Function
- Sharpness;Mirror;Brightness;Anti-Banding;Smart Light;Contrast
- Video Outputs
- 1 HD analog output
- Operating Conditions
- -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply
- 12 VDC ± 25%/PoC.at
- Protection Level
- IP67
- White Light Range
- Up to 40 m
- Dimensions
- 194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
- Weight
- Approx. 566 g (1.25 lb.)
- Brackets
- DS-1280ZJ-XS
Technical Specifications
Frequently Asked Questions
What is the maximum resolution of the DS-2CE12UF3T-E?
8MP, with a maximum video resolution of 3840 × 2160.
Which video formats does this camera support?
HD-TVI, AHD, CVI, and CVBS, so it works across most existing analogue DVR setups.
What lens options are available?
Fixed focal lenses in 2.8mm, 3.6mm, or 6mm, selected at order stage for the required field of view.
Is the camera suitable for outdoor use?
Yes, the housing is IP67-rated for dust and water resistance.
