Product Description
The HDT-2MP-DHW-AUDIO-3.6MM is a 2MP turret camera outputting 1920×1080 over coaxial, switchable between TVI, AHD, CVI and CVBS via OSD menu — drop it into any existing HD analogue DVR run without swapping the head-end format.
Key specs
- Resolution: 2MP (1920×1080), HD-TVI native
- Lens: 3.6mm fixed
- Video output: 4-in-1 switchable (TVI/AHD/CVI/CVBS)
- Audio: built-in microphone, audio carried over the coax run alongside video
- IR illumination: up to 20 metres, with automatic IR cut filter for True Day/Night switching
- Power: 12V DC
- Weather rating: IP66
- Housing: turret, compact form factor, for ceiling or wall mounting
On the job
Because output format is menu-selectable, this turret suits mixed-generation DVR estates where channels run different analogue HD standards — reconfigure per channel rather than stocking separate camera SKUs. The built-in mic means audio rides the same coax feed, so no separate audio cable pull is needed to add sound to a channel.
IP66 rating covers outdoor mounting; the 12V DC supply and 20m IR range are the figures to check against your existing PSU and any low-light coverage spec before quoting a job. Fixed 3.6mm lens gives one set field of view — no varifocal adjustment on site.
Frequently Asked Questions
Which analogue HD formats does this camera support?
It's a 4-in-1 design switchable between TVI, AHD, CVI and CVBS via the OSD menu, so it can match whichever standard your DVR channel runs.
Does the audio need a separate cable run?
No — the built-in microphone sends audio over the same coaxial cable as the video signal.
What power supply does it need?
It runs on 12V DC.
How far does the IR night vision reach?
IR illumination is rated up to 20 metres, with an automatic IR cut filter for True Day/Night switching.
