Product Description
DS-2CD1327G2-LUF: 2MP ColorVu turret for spec-driven installs
A fixed-lens 2MP turret built for jobs where full-colour night footage and single-cable deployment matter more than headline resolution.
Sensor and optics
- 1/2.8" progressive scan CMOS, 1920×1080 output
- Fixed 2.8mm lens, 106° horizontal FoV — no field-adjustable focal length, so confirm coverage before spec'ing on longer throws
- F1.0 aperture (ColorVu) — gathers markedly more light than standard-aperture lenses, holding full colour rather than dropping to IR mono at night
- White-light illumination to 30m, in place of IR
Compression and bandwidth
Supports H.265+, H.265, H.264+ and H.264, giving integrators the option to cut stream bitrate on constrained NVR storage or uplinks without dropping to H.264 baseline.
Power and cabling
PoE (IEEE 802.3af) or 12V DC. On PoE runs, budget standard 802.3af allowance per camera when sizing switch/NVR PoE budgets across a multi-camera install — no PoE+ requirement stated for this model.
Analytics and audio
Onboard human and vehicle detection for classified event triggers, reducing false alarms from foliage or lighting changes versus basic motion detection. Built-in microphone captures synchronised audio with the video stream.
Environmental and integration
IP67-rated housing for external mounting. Integrates with Hikvision NVRs and ONVIF-compliant VMS platforms, so it drops into mixed-vendor estates as well as native Hikvision setups.
MPN: DS-2CD1327G2-LUF-2.8MM-W.
Specifications
- Brand
- Hikvision
- ColorVu
- Yes
- Built-in Microphone
- Yes
- Motion Detection
- Basic
- Human Detection
- Yes
- Vehicle Detection
- Yes
- Line Crossing
- No
- Intrusion Detection
- No
- Face Detection
- No
- Face Recognition
- No
- False Alarm Filtering
- Yes
- AI Analytics
- Yes
- PoE Support
- Yes
- PoE Standard
- IEEE 802.3af, Class 3
- Power Supply
- 12V DC ±25% PoE 802.3af, 36V to 57V
- Max Power
- 6.5W max
- IP Rating
- IP67
- Video Compression
- H.265+
- SD Card Slot
- Yes
- Max SD Card Size
- 512GB
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
- Audio
- Built-in Microphone
- Smart Detection
- Human/Vehicle AI
- Illumination
- 30m White Light
- Intelligence
- Motion Detection
Technical Specifications
Frequently Asked Questions
Does the DS-2CD1327G2-LUF require PoE+ or does standard PoE cover it?
It supports IEEE 802.3af PoE as well as 12V DC, so standard PoE budgeting applies rather than PoE+ (802.3at).
Can this camera run without infrared at night?
Yes — it uses white-light illumination up to 30m with an F1.0 ColorVu lens instead of IR, keeping full colour after dark.
What compression formats does it support for NVR storage planning?
H.265+, H.265, H.264+ and H.264, letting you drop bitrate via H.265+ where NVR storage or uplink bandwidth is tight.
Is the fixed lens field of view adjustable on site?
No, the lens is fixed at 2.8mm giving a 106° horizontal field of view, so coverage must be confirmed against the mounting position before install.
Does it integrate with non-Hikvision VMS platforms?
Yes, it integrates with Hikvision NVR systems and ONVIF-compliant video management platforms.
