Product Description
The Hikvision DS-2AE5225TI-A-E is a 2MP Turbo HD PTZ speed dome built for jobs that need one camera to both patrol a wide area and pull in detail from distance.
Key specs
- 1/2.8" progressive scan CMOS sensor delivering 1920×1080 Full HD resolution
- 25× optical zoom, 4.8–120 mm motorised lens, plus 16× digital zoom for additional reach
- Smart IR night vision to 150 m, for low-light or dark-site coverage
- HD-TVI and CVBS BNC output, so it drops into either a Turbo HD DVR or a simpler analogue setup
- 120 dB True WDR and 3D DNR, for clarity against strong backlight or noisy low-light footage
- 360° continuous pan with wide tilt range, plus preset positions, patrol paths and pattern scanning
- IP66 housing rated for outdoor installation
Where it fits
On a perimeter or car park, the 360° pan and preset patrol paths mean one unit can cover ground that would otherwise need several fixed cameras. The 25× optical zoom is what earns its keep here — an operator can hold wide coverage and still zoom to read a plate or check an entry point without repositioning the camera.
Integration note
Output over HD-TVI keeps it compatible with existing Turbo HD DVR infrastructure; the CVBS BNC option covers sites still running standard analogue. True WDR and 3D DNR are worth specifying where the mounting position faces strong sun, headlights, or low-light noise.
Specifications
- Brand
- Hikvision
- IP Rating
- IP66
- Resolution
- 2MP
Technical Specifications
Frequently Asked Questions
What video outputs does the DS-2AE5225TI-A-E support?
It supports both HD-TVI and CVBS BNC output, so it works with a Turbo HD DVR or a standard analogue setup.
How far does the zoom and IR reach on this camera?
It has 25x optical zoom via a 4.8–120 mm motorised lens (16x digital zoom on top), and Smart IR night vision up to 150 metres.
Is the DS-2AE5225TI-A-E suitable for outdoor installation?
Yes, it has an IP66 weather-resistant housing designed for outdoor use.
Does it support patrol and preset functions?
Yes, the PTZ mechanism gives 360° continuous pan and adjustable tilt, with preset positions, patrol paths and pattern scanning.
