Product Description
The PROLUX HDT-2MP-N20W-2.8MM is a 2MP dome camera with switch-selectable 4-in-1 output, covering TVI/AHD/CVI/CVBS from a single HD analogue video connection. That switch button lets you match the camera to whatever format your DVR is already running, without swapping hardware.
Key specs
- Sensor: 2MP CMOS, 1920×1080
- Lens: 2.8mm fixed, M12 mount, 103° horizontal field of view
- IR: EXIR 2.0 smart IR, up to 20m range, IR cut filter for day/night switching
- Video output: 1 HD analog output, switchable TVI/AHD/CVI/CVBS
- Power: 12VDC ±15%, max 4W
- Housing: IP66, metal, operating range -40°C to 60°C
- Dimensions/weight: Ø82.6mm × 69.66mm, 230g
The 2.8mm lens keeps the field of view wide, which suits entrances, counters and small yards where coverage close to the camera matters more than throw distance. Menu-side it offers AGC, auto/colour/BW day-night mode, backlight compensation and DWDR, all set through the on-screen menu in English.
Angle adjustment covers 0°–360° pan, 0°–75° tilt and 0°–360° rotation, so alignment on a wall or ceiling mount is straightforward once fixed. IP66 rating suits outdoor and unsheltered mounting positions.
Confirm your recorder's accepted format before install — only one signal type runs at a time via the switch, not all four simultaneously.
Specifications
- Brand
- Generic
- Camera Type
- Analog Camera
- Resolution
- 2MP (1080p)
- Housing Material
- Plastic
- Smart Hybrid Light
- IR Only
- IR Distance
- 20m
- Connection Type
- Analogue
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
Technical Specifications
Frequently Asked Questions
Which video formats does this camera support?
It outputs one HD analog signal at a time, switchable between TVI, AHD, CVI and CVBS via the switch button — check your DVR's format before ordering.
What's the IR range on this camera?
EXIR 2.0 smart IR gives up to 20m range, with an IR cut filter handling the day/night switch automatically.
Is this camera rated for outdoor use?
It carries an IP66 ingress rating and an operating range of -40°C to 60°C.
What field of view does the 2.8mm lens give?
The 2.8mm lens gives a 103° horizontal field of view, suited to close-in coverage like entrances or counters.
