Product Description
Key specs
The DS-2DE5232IW-AE(S6) is a 2MP PTZ speed dome built for long-range coverage of large outdoor areas — roads, perimeters, public squares, industrial sites — rather than close-in doorway monitoring.
- Sensor: 1/2.8″ progressive scan CMOS, up to 1920×1080
- Zoom: 32× optical (4.8–153mm motorised) plus 16× digital
- IR range: up to 150m, with Powered-by-DarkFighter low-light processing
- Pan/tilt: 360° continuous pan, −15° to 90° tilt
- Presets: up to 300 preset positions, with patrol scans and pattern scans
- Compression: H.265+ / H.265 / H.264+
- Power: PoE+ (802.3at) or 24 VAC
- Housing: IP66-rated, with lightning and surge protection
Image processing
120 dB WDR, 3D digital noise reduction, defog, HLC and BLC are all onboard, covering the usual problem cases — headlights, mist, mixed bright/dark scenes — that a single-exposure camera struggles with.
PTZ and integration notes
Full 360° continuous pan with −15° to 90° tilt removes blind spots behind or above the mount. With 300 presets plus patrol and pattern scans, one camera can cover several zones on an automated tour instead of running multiple fixed units. PoE+ (802.3at) support means it drops onto a standard PoE+ switch port without a separate 24 VAC run, though that option remains available where PoE budget or cable length is a constraint.
Specifications
- Brand
- Hikvision
- Resolution
- 2MP
Technical Specifications
Frequently Asked Questions
What is the IR range on the DS-2DE5232IW-AE(S6)?
Up to 150 metres, supported by Hikvision's Powered-by-DarkFighter low-light technology.
Does this camera support PoE?
Yes, it supports PoE+ (802.3at) as well as 24 VAC power.
How far can the zoom lens reach?
It has a 4.8–153mm motorised lens giving 32× optical zoom, plus a further 16× digital zoom.
How many preset positions does it support?
Up to 300 preset positions, with patrol scan and pattern scan functions for automated coverage.
