Product Description
NVR-108H-D/8P is an 8-channel PoE network video recorder built for small to medium IP CCTV installs, with built-in PoE ports removing the need for separate injectors on each camera run.
Key specs
- 8 channels, up to 8 IP cameras supported
- Built-in PoE — power and data over a single Ethernet cable per camera
- 60 Mbps total incoming/outgoing bandwidth budget
- Compression: H.265+, H.265, H.264+, H.264
- Up to 4-channel 1080p simultaneous decoding for live view/playback
- HDMI and VGA outputs, run simultaneously
- Mini 1U chassis for rack, cabinet or desktop siting
On the job
With an 8-camera ceiling and a 60 Mbps bandwidth budget, this unit suits sites where camera count and resolution are modest — think a shop, small office or residential block rather than a multi-building estate. Because PoE is built into the recorder, there's one cable per camera to plan for, which simplifies containment on retrofit jobs where running separate power is impractical.
The 4-channel 1080p simultaneous decoding limit is worth checking against the client's monitoring setup: full 8-camera live view at higher resolutions may exceed decode capacity even though all 8 channels can record. H.265+/H.265 support helps keep storage sizing down on longer retention specs. Dual HDMI/VGA output means the same feed can go to a monitor and a VGA-only display concurrently, useful where legacy screens are still in place.
Specifications
- Brand
- Hilook
- Channels
- 8
- Colour
- Black
- Max Resolution
- 6 MP
- Storage Capacity
- Up To 6 TB
- Video Compression
- H.265/H.264/H.265+/H.264+
- Video Outputs
- HDMI, VGA
Technical Specifications
Frequently Asked Questions
How many cameras can the NVR-108H-D/8P support?
Up to 8 IP network cameras, each powered via the recorder's built-in PoE ports.
Does it need a separate PoE switch for the cameras?
No — PoE is built into the 8 channels, so each camera gets power and data over one Ethernet cable direct to the NVR.
Can all 8 channels display in live view at once at full resolution?
The unit records 8 channels but simultaneous decoding is rated at up to 4 channels at 1080p, so check this against the intended monitoring setup.
What video outputs does it have?
HDMI and VGA, and both can be used simultaneously.
