Product Description
Hikvision iDS-7208HQHI-M1/XT — 8-channel 1U AcuSense DVR
An 8-channel, 1-bay HDD hybrid DVR built for jobs mixing analogue and IP cameras on a single recorder. It accepts five signal types adaptively — HDTVI, AHD, CVI, CVBS and IP — so existing analogue cable runs stay usable while the system scales toward IP.
Up to 12-ch network cameras can be connected via the hybrid IP capability, giving flexibility for sites moving toward IP without a forklift upgrade.
Recording and compression
- H.265 Pro+ compression cuts bandwidth and storage load versus older codecs — factor this into HDD sizing.
- Encoding up to 3K/5MP Lite at 12fps balances image detail against drive capacity.
- One SATA interface, supporting up to 10TB of storage.
Detection and analytics
- AcuSense deep-learning analytics classifies people and vehicles separately from other motion, cutting false triggers from weather, animals or headlights.
- Facial recognition on 2 channels, or perimeter protection (line crossing, intrusion) on 4 channels, both deep-learning based.
- AcuSearch technology on 4 channels for faster event review.
- Motion detection and HDTVI two-way audio supported across all 8 channels.
Outputs and remote access
HDMI and VGA outputs deliver Full HD local monitoring. Remote access is supported via Hik-Connect and ONVIF-compatible platforms, useful where this DVR sits alongside third-party VMS or NVR estate.
Suitable for retail, office, commercial and residential installs needing intelligent detection without a full IP camera swap-out.
Specifications
- Model
- iDS-7208HQHI-M1/XT
- Series
- M-Series
- Max Resolution
- 5MP Lite
- Colour
- Black
- Max Analog Resolution
- 5MP
- IP Channels (Hybrid)
- Up to 12
- Video Compression
- H.265 Pro+, H.265 Pro, H.265, H.264+, H.264
- Recording Resolution
- 5MP Lite, 3K Lite, 4MP Lite, 1080p Lite, 720p
- Frame Rate
- 12 fps @ 5MP Lite / 15 fps @ 4MP Lite
- Decoding Capability
- 8 Channels
- BNC Output
- Yes
- Max Total Storage
- 10TB
- AcuSense
- Yes
- DeepinMind / AI
- No
- Human & Vehicle Detection
- Yes
- Face Detection
- Yes
- Face Recognition
- Yes
- Perimeter Protection
- Yes
- Line Crossing
- Yes
- Intrusion Detection
- Yes
- False Alarm Filtering
- Yes
- People Counting
- No
- Audio Input
- 1 RCA + 8 via coax
- Audio Output
- 1 RCA
- Two-Way Audio
- Yes
Technical Specifications
Frequently Asked Questions
Does this DVR support IP cameras as well as analogue?
Yes — it accepts HDTVI, AHD, CVI, CVBS and IP signals adaptively, and up to 12-ch network cameras can be connected via its hybrid IP capability.
What resolution and frame rate can it record at?
Up to 3K/5MP Lite at 12fps, using H.265 Pro+ compression to reduce storage and bandwidth demand.
How much storage does the iDS-7208HQHI-M1/XT support?
It has one SATA interface supporting up to 10TB of HDD capacity.
What analytics does AcuSense provide on this model?
AcuSense classifies people and vehicles to cut false alarms, plus facial recognition on 2 channels or perimeter protection on 4 channels.
