Product Description
THC-T250-M-R — 5MP Turbo HD mini turret
Switchable HD-TVI, AHD, CVI and CVBS output means this turret runs on any Turbo HD DVR already on site — confirm the DVR channel supports the required format before spec'ing.
Housing: metal and plastic, IP66-rated, suited to entrance, corridor and other exposed mounting points.
Optics: fixed lens, supplied as either 2.8 mm or 3.6 mm variant — check SKU before ordering to match the required field of view.
Night performance: built-in IR to 20 metres, with Smart IR regulating exposure so foreground subjects near the lens aren't overexposed. The camera switches to colour output in daylight and monochrome IR at night.
Image processing
- Digital Wide Dynamic Range for mixed-light scenes
- Digital noise reduction for low-light clarity
Power and connection
Runs on 12V DC, connecting to a compatible DVR over coaxial cable. Because output format is switchable rather than fixed, one camera SKU covers HD-TVI, AHD, CVI or CVBS installs without needing separate part numbers per protocol.
Compact turret form factor suits jobs where a dome or bullet housing is too large or too conspicuous — corridors, doorways and similar close-range coverage points.
Specifications
- Brand
- Hilook
- Model
- THC-T250-M-R
- Camera Type
- Analog Camera
- Built-in Microphone
- Yes
- Built-in Speaker
- No
- Two-Way Audio
- No
- Motion Detection
- Basic
- Connection Type
- Analogue
- PoE Support
- No
- Power Supply
- 12V DC
- IP Rating
- IP66
- SD Card Slot
- No
- App Compatibility
- iVMS
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
Technical Specifications
Frequently Asked Questions
What video formats does the THC-T250-M-R support?
It supports switchable HD-TVI, AHD, CVI and CVBS output, so it can run on any DVR accepting one of those formats.
What is the IR range?
Built-in infrared gives night vision up to 20 metres, with Smart IR controlling exposure for closer subjects.
What is the housing rating?
The metal and plastic housing is IP66-rated, suitable for outdoor mounting points such as entrances and corridors.
What power does it need?
The camera operates on 12V DC and connects to a compatible DVR over coaxial cable.
