Product Description
DS-KIS603-P(C) is Hikvision's single-call-button villa kit, supplied as a fixed bundle rather than a pick-and-mix — the SKU confirms exactly what's in the box, which matters for quoting and job-costing.
What's in the box
- 1 × DS-KV6113-WPE1(C) door station (single call button)
- 1 × DS-KH6320-WTE1 indoor monitor
- 2 × PSU (power adapters included)
No additional accessories, modules or spare handsets are bundled under this MPN — if a job needs more than one indoor monitor or a multi-button door station, that's a different kit or an add-on purchase, not this one.
Specification notes for installers
- Door station: DS-KV6113-WPE1(C), one call button — suited to single-entrance villas/houses rather than multi-tenant entry panels.
- Indoor monitor: DS-KH6320-WTE1, paired directly with the above door station in this bundle.
- Power: two PSUs supplied — one per device — so no separate power budget calculation is needed on install.
- Remote access: Hik-Connect app support for mobile call handling and monitoring away from the property.
Where it fits
This is a residential/single-dwelling intercom solution rather than a commercial multi-door system. For quoting purposes, treat the SKU as one fixed unit: door station, monitor and both PSUs together, not sold as separable line items.
Specifications
- Operating System
- Embedded Linux operation system
- Flash
- 32 MB
- RAM
- 256MB
- Camera
- 2MP HD camera
- Night vision
- Low illumination IR supplement mode:3 m
- Backlight Compensation
- Support
- Digital Noise Reduction
- Support
- WDR
- True WDR
- Field of View
- Horizontal: 131° Vertical: 78°
- Video Compression Standard
- H.264
- Stream
- Main stream: 1080p@30fps, 720p@25fps Sub stream: D1@25fps
- Motion detection
- Support
- Flash-Avoid Frequency
- 50 Hz, 60 Hz
- Audio input
- Built-in omnidirectional microphone
- Audio output
- Built-in loudspeaker
- Audio Quality
- Noise suppression and echo cancellation
- Audio Intercom
- Two-way audio communication
- Wired Network
- 10/100 Mbps Ethernet
- Power supply
- IEEE802.3af, standard PoE 12 VDC
- Memory
- Embedded Linux operation system
- Manufacturer
- Hikvision
Technical Specifications
Frequently Asked Questions
What exactly is included with the DS-KIS603-P(C) kit?
One DS-KV6113-WPE1(C) door station with a single call button, one DS-KH6320-WTE1 indoor monitor, and two power supply units — one PSU per device.
Is a separate power adapter needed for install?
No — two PSUs are supplied in the kit, covering both the door station and the indoor monitor.
Can this kit be monitored remotely?
Yes, it supports the Hik-Connect app for mobile call handling and monitoring.
Is this suited to multi-entrance commercial buildings?
The door station in this bundle has a single call button, making it suited to single-entrance villa or house installations rather than multi-tenant panels.
