Product Description
Install-level facts
The DS-KIS101-P/Surface is a 2-wire analog kit — door station, indoor monitor and power adapter as a matched set, not a modular platform. Confirm this before quoting against IP-based Hik-Connect kits; it does not share config or wiring topology with those ranges.
- Wiring: 2-core, power and video/audio on the same run — no network switch, no PoE, no separate lock PSU required for the standard load.
- Lock output: two relay outputs; one can be powered directly from the kit at up to 12V 1A, so a single maglock or strike within that rating needs no extra power supply on site.
- Door station: surface-mount, IP65 and IK07 — rated for external entrance mounting and impact exposure.
- Call button: one-touch nametag button, single-station operation — this is a single-door, single-tenant kit, not a multi-way panel.
Where this fits
Use it for retrofit jobs where structured cabling isn't in place — the 2-wire run is the point: existing bell wire or similar low-cost cabling can often be reused, subject to run length and condition, saving a full re-cable. It's a fit-and-forget residential or small-premises door entry job rather than a component in a larger access-control system — there's no integration with NVRs, ANPR or multi-door controllers in this kit.
Indoor station handles call answer, two-way audio and door release; there's no mention of recording or video storage in this kit, so treat it as intercom-only, not a CCTV substitute.
Specifications
- Operating System
- Embedded analog operation system
- Supplement Light
- White light supplement
- Max Resolution
- 2MP
- Audio Input
- Built-in omnidirectional microphone
- Audio Output
- Built-in loudspeaker (More than 80 dB within 20 cm)
- Volume Adjustment
- Adjustable with screwdriver
- Lock Control
- 2, lock duration can be adjusted via DIP switch (Max. 7 s)
- Power Supply for Lock
- 1, Max. 12 V 1 A
- Installation
- Surface mounting with protective shield
- Protection Rating
- IP65, IK7
- Operating Temperature
- -30 °C to +60 °C (-22 °F to 140 °F)
- Operating Humidity
- 10% to 90%
- Dimensions
- 150 mm × 82 mm × 23.5 mm (5.91" × 3.23" × 0.93")
- Power Supply
- 48 VDC, 0.5 A
- Application Environment
- Outdoor
- Max Power Consumption
- ≤ 12 W
- Size
- 7-inch TFT non-touch screen
- Operation Method
- 6 touch buttons
- Type
- Colourful TFT screen
- Volume
- Adjustable via touch-button
- Dimensions (W × H × D)
- 187 mm × 137 mm × 25.4 mm (7.36" × 5.39" × 1.00")
Technical Specifications
Frequently Asked Questions
Does this kit require network/PoE cabling?
No — it runs on a 2-wire connection carrying both power and communication, so no network switch or PoE injector is needed.
Can the kit power an electric lock directly?
Yes, one of the two lock relay outputs can supply power directly to an electric lock rated up to 12V 1A, avoiding the need for a separate lock power supply.
Is the door station suitable for outdoor mounting?
Yes, the outdoor station is IP65 rated for weather protection and IK07 rated for impact resistance, and is designed as a surface-mount unit.
Does this kit support multiple entrances or tenants?
No — the kit is built around a single door station with one call button and one indoor monitor, so it's designed for single-door, single-tenant installations.
