Product Description
Point-to-point HDMI extension over a single Cat5e/Cat6 run — 1080p @ 60Hz, max 30m (100ft), transmitter and receiver kit with 2x EU PSU included.
Key specs
- Video: Full HD 1080p @ 60Hz — no 4K support
- Run length: up to 30m / 100ft over one Cat5e or Cat6 RJ45 cable
- Audio: pass-through supporting DTS-HD, Dolby TrueHD, DTS and Dolby Digital
- Setup: plug-and-play, no software or network switch required
- EDID copy: for handshake compatibility across TVs, monitors and projectors
- No IR pass-through — factor this into control-layer design on install
- Cat6 pure-copper cable recommended for best signal integrity over the full 30m
Deployment notes for installers
This is a direct TX/RX pair, not a network-switched solution — it does not route through a LAN switch, so cable run distance is the hard limit at 30m regardless of Cat5e or Cat6. Sold specifically for use with DVR/NVR CCTV outputs (IP and analogue), home cinema, classroom AV and digital signage runs where a single Ethernet-style cable is more practical to pull than a long HDMI lead.
Box contents
1x Transmitter, 1x Receiver, 2x 5V power adapters, 1x user manual.
Note the two limitations before specifying this on a job: 1080p is the ceiling (no 4K), and there's no IR pass-through, so any source needing remote control at the display end will need a separate IR extension path.
Specifications
- Product Type
- HDMI Extender over RJ45
- Maximum Resolution
- Full HD 1080p at 60Hz
- Maximum Transmission Distance
- 30 metres / approximately 100 ft
- Cable Compatibility
- Single Cat5e or Cat6 cable
- Power Supply
- 2 × 5V power adapters included
- Package Contents
- 1 × transmitter, 1 × receiver, 2 × power adapters, 1 × user manual
Frequently Asked Questions
What is the maximum run length for this extender?
Up to 30 metres (100ft) over a single Cat5e or Cat6 RJ45 cable.
Does it support 4K?
No — this kit is rated for 1080p Full HD at 60Hz, not 4K.
Is IR pass-through included for remote control?
No, there is no IR pass-through on this kit, so remote control signals won't travel over the same run.
Which cable type gives the best performance?
Cat6 pure-copper cable is recommended for best performance over the full 30m run.
What's included in the box?
One transmitter, one receiver, two 5V power adapters and a user manual.
