Product Description
What it does
Runs 4K HDMI video, audio and USB keyboard/mouse control over a single Cat5e or Cat6 cable, extending an HDMI source up to 60m (200ft). Built for pulling a DVR, NVR or PC out of the room while the operator keeps full local control.
Key specs
- Video/audio: 4K HDMI with full audio, carried over one RJ45 run
- Distance: up to 60m (200ft) on Cat5e or Cat6
- KVM: built-in USB ports for keyboard/mouse pass-through — operate the source as if sat next to it
- Setup: plug-and-play, no drivers or software
- Topology: point-to-point only — no switch between TX and RX
- Cable note: pure-copper Cat6 recommended to hit the full 60m reach; poor-quality or CCA cable will shorten achievable distance
In the box
HDMI-to-RJ45 transmitter, RJ45-to-HDMI receiver, two power adapters, user manual.
Where it's specified
CCTV control rooms and server rooms — DVR/NVR stays in the rack, operator gets screen and USB control at the desk. Also fits industrial monitoring stations, digital signage and retail/hospitality display runs where the source has to sit away from the viewing position.
Because it's point-to-point, this extender doesn't share bandwidth with a camera network and won't run through a network switch — it needs a dedicated Cat5e/Cat6 run between TX and RX.
Specifications
- Product Type
- HDMI KVM Extender over RJ45
- Model / SKU
- HDMI-EXTENDER-Over-Ethernet-RJ45-4K-KVM-60m
- Maximum Resolution
- 4K; refresh rate not specified
- Maximum Transmission Distance
- Up to 60 metres / approximately 200 ft
- Cable Compatibility
- Single Cat5e or Cat6 cable
- Audio Support
- HDMI audio transmission
- USB Function
- Keyboard and mouse pass-through
- Installation
- Plug-and-play; no drivers or software required
- Power Supply
- 2 power adapters included
- Package Contents
- 1 × transmitter, 1 × receiver, 2 × power adapters, 1 × user manual
Technical Specifications
Frequently Asked Questions
What's the maximum distance for this extender?
Up to 60 metres (200ft) over a single Cat5e or Cat6 cable; pure-copper Cat6 is recommended to reach the full distance.
Can it run through a network switch?
No — it's a point-to-point connection, with no switch between the transmitter and receiver.
Does it need drivers or software?
No, it's plug-and-play — connect the transmitter to the HDMI source and the receiver to the monitor and it works.
Does it carry USB keyboard and mouse as well as video?
Yes, the built-in USB ports pass through keyboard and mouse control alongside 4K video and audio on the same cable.
