Product Description
HDMI extender kit transmitting HDMI video and audio over Cat5e/Cat6 cable via RJ45 LAN ports, rated for a 30 metre run between transmitter and receiver.
Key specs
- Signal path: HDMI in at the TX unit, HDMI out at the RX unit, carried over standard Cat5e/Cat6 Ethernet cable via RJ45 connectors
- Max distance: 30 metres between transmitter and receiver
- Resolution: Full HD 1080P
- Audio: embedded audio passed through the same link as the video signal, so no separate audio run is needed
- Kit contents: one transmitter (TX) unit and one receiver (RX) unit
- Install: plug and play, no software or configuration step described
Deployment notes
The TX unit connects to the source — DVR, NVR, media player, TV box or PC — and the RX unit connects to the display: monitor, HDTV or projector. Running standard network cable instead of long HDMI runs simplifies containment and first-fix cable routing on install jobs.
This is a point-to-point extender: one TX paired with one RX over a single Cat5e/Cat6 run, not a matrix or multi-drop distribution unit. Relevant for CCTV monitoring walls, conference room displays, home theatre installs and digital signage where the display sits away from the source.
No IR pass-through, PoE, or additional control channel is described for this unit — confirm against the job spec before quoting.
Specifications
- Colour
- Black
- Connector Type
- RJ45
Frequently Asked Questions
What is the maximum extension distance?
Up to 30 metres between the transmitter and receiver units.
Does it carry audio as well as video?
Yes, both HDMI video and audio are transmitted together over the Ethernet cable.
What cable does it use?
Standard Cat5e or Cat6 Ethernet cable connected via RJ45 LAN ports.
What resolution does it support?
Full HD 1080P video.
