Product Description
A 1.5m HDMI-A male-to-male lead built for NVR-to-monitor runs in control rooms and racks, not living-room AV.
Key specs
- HDMI 2.0 Premium High Speed certified — 18Gbps bandwidth, 4K@60Hz (3840x2160) at 4:4:4 chroma, HDR support
- 30-34AWG OFC conductors with triple shielding (foil + braid) and gold-plated contacts for low-loss, interference-resistant transmission
- HDCP 2.2, ARC, CEC and Ethernet channel supported
- PVC jacket, 4.5-6mm OD, moulded strain relief
- Backward compatible with HDMI 1.4 — runs 1080p@120Hz on legacy sources
- RoHS compliant, rated for 10,000+ mating cycles
Why the spec matters on site
The triple shielding and gold contacts are there to reject EMI in a rack full of PSUs and switching gear — a common cause of dropped or flickering HDMI feeds when cables run alongside power leads. At 18Gbps the cable has headroom for full-chroma 4K@60Hz, so NVR outputs feeding UHD monitors won't be bandwidth-limited by the lead itself.
Fit and installation
At 1.5m this is a rack-to-console length — no booster needed between an NVR and an adjacent monitor. The flexible PVC jacket sits comfortably in cable trays next to Cat5e, DC pigtails and other rack infrastructure, and the moulded strain relief protects the connector under repeated rack access.
Compatibility
HDMI 1.4 backward compatibility means the same lead handles 1080p@120Hz sources, useful where 4K and legacy NVRs share a rack.
Specifications
- Product Type
- 4K High Speed HDMI Cable
- Connector Type A
- HDMI Type A Male (19-pin)
- Cable Length
- 1.5
- HDMI Version
- 2.0 Premium High Speed
- Max Resolution
- 4K (3840x2160) @60Hz
- Bandwidth
- 18 Gbps
- Shielding
- Triple (Foil + Braid)
- Conductor Material
- Oxygen-Free Copper (OFC)
- Wire Gauge
- 30-34 AWG
- Diameter
- 4.5-6
- Contacts
- Gold-plated
- Supported Features
- ARC, CEC, HDCP 2.2, Ethernet, HDR
- Colour
- Black
Frequently Asked Questions
Does this cable support full 4K at 60Hz?
Yes — it's HDMI 2.0 Premium High Speed certified with 18Gbps bandwidth, delivering 4K@60Hz (3840x2160) at 4:4:4 chroma with HDR support.
Will it work with older 1080p NVRs?
Yes, it's backward compatible with HDMI 1.4, supporting 1080p@120Hz for legacy sources.
Is it suitable for use in a rack near PSUs and Ethernet cabling?
Yes — triple shielding (foil plus braid) and gold-plated contacts are specified for EMI resistance in rack environments with PSUs.
Does it support HDCP 2.2 for protected content?
Yes, HDCP 2.2 is supported, along with ARC, CEC and an Ethernet channel.
