What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
16 cameras included, keeps about 8 days of footage, uses analogue cameras; check existing coax cable condition and compatibility before reuse.
Recorder capacity
16 included cameras use 16 of the recorder’s 16 channels. All stated channels are occupied. A larger system needs a recorder with additional capacity.
Recording storage
6TB storage is included. Estimated recording time: about 8 days with continuous H.265 recording. The estimate uses 2 Mbps per camera up to 2MP, 4 Mbps up to 5MP and 8 Mbps above 5MP, summed for mixed camera models. Actual retention depends on settings, scene activity and usable drive capacity; motion-only recording varies with activity.
Before installation
Check the component list below for included cables, power supplies and mounting accessories. Choose cable lengths and camera positions for your layout; camera count alone does not establish coverage. Confirm lens field of view, lighting and weather protection for each position.
The recorder
Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR)
The box that saves everything and runs the app
The cameras× 16
Hikvision 5 MP PIR Fixed Turret Camera
What goes on the wall
The hard drive
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
One plug that powers the cameras
The cable× 16
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 16-channel HD-over-coax CCTV kit built on the XVR-3116HS-5MP-LITE + 16× Hikvision DS-2CE71H0T-PIRLO. 16 cameras at 5MP — sized for a larger property or yard. The included 6TB surveillance hard drive holds about 8 days of continuous recording — the estimate assumes recording all 16 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 16× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR); 16× Hikvision 5 MP PIR Fixed Turret Camera; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 16× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit.
Specifications
- System type
- Analog (HD over coax)
- Built on
- XVR-3116HS-5MP-LITE + 16× Hikvision DS-2CE71H0T-PIRLO
- Recorder
- 16-channel Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR)
- Cameras included
- 16× Hikvision 5 MP PIR Fixed Turret Camera
- Camera resolution
- 5MP
- Storage
- 6TB surveillance HDD — about 8 days of footage, recording all 16 cameras continuously at high quality (H.265)
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit; 16× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- What's in the box
- 1× Unbranded – 16 Channel 5MP HYBRID Digital Video Recorder (DVR); 16× Hikvision 5 MP PIR Fixed Turret Camera; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 16× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
