Product Description
DS-1280ZJ-TR13-W is Hikvision's aluminium alloy junction box for turret CCTV cameras, giving installers a concealed cable-routing base for wall or ceiling mounts.
Key specs
- Diameter: approx. 110 mm
- Height: approx. 48 mm
- Material: aluminium alloy — corrosion-resistant, lightweight
- Finish: white, matched to Hikvision turret camera housings
- Also listed as: DS-1280ZJ-TR13, GR-DS-1280ZJ-TR13-W-LN
- Use: indoor and outdoor installations, wall or ceiling fixing
On site, the enclosure lets you route and terminate network and power cabling inside the housing rather than leaving connectors exposed at the camera base — useful on concrete walls or ceilings where surface conduit isn't practical. The internal cavity is sized to hold standard connectors and the slack needed for a typical turret install, keeping the termination protected from weather and knocks once sealed up.
Compatibility note
This box is built for selected Hikvision turret camera models — it is not a universal fit across the turret range. Confirm the exact camera model against Hikvision's mounting compatibility before ordering, since mismatched base diameters or fixing points will prevent a clean fit.
Finished in white to sit flush against Hikvision's standard turret camera colourway, the DS-1280ZJ-TR13-W is intended for professional CCTV installs where a tidy, protected cable entry is part of the spec.
Specifications
- Brand
- Hikvision
- Colour
- White
- Weight
- Approx. 187 g (0.41 lb.)
- Appearance
- Hikvision White
- Material
- Aluminium Alloy
- Dimensions
- Φ 110 mm × 144.3 mm × 48 mm (Φ 4.33" × 5.68" × 1.89")
- Description
- Junction Box
Technical Specifications
Frequently Asked Questions
Will the DS-1280ZJ-TR13-W fit any Hikvision turret camera?
No — it's designed for selected Hikvision turret models only, so check your specific camera against the mounting compatibility before ordering. Buyers have reported fit issues when this wasn't checked first.
What are the dimensions of this junction box?
It measures approximately 110 mm in diameter and 48 mm in height, giving enough internal space for standard connectors and cable slack.
What is it made from?
An aluminium alloy body, chosen for durability and corrosion resistance in both indoor and outdoor installations.
Can it be used for ceiling mounting as well as walls?
Yes, the enclosure is designed for both wall and ceiling mounting applications.
