Product Description
What it is
The DS-1280ZJ-DM46 is a junction box that mounts between a wall or ceiling and a compatible Hikvision dome camera, giving cable connections a concealed, protected cavity instead of leaving them exposed.
Key specs
- Construction: aluminium alloy enclosure
- Load capacity: up to 4.5 kg — check against the mounted camera's declared weight before specifying
- Rating: suitable for indoor and outdoor installations
- Cable entry: bottom entry, routed within the enclosure for a concealed run
- Finish: white, matching Hikvision dome camera housings
- Model: DS-1280ZJ-DM46 (also listed as DS-1280ZJ-DM46-W)
Why it matters on site
On solid masonry or ceiling mounts there's often no cavity to drop cable into. This box provides that cavity, keeping power and network connectors out of the weather and out of sight — useful where a clean finish or IP-rated cable protection is specified. The bottom-entry design keeps the run tidy whether the drop comes from above or below.
Fit and compatibility
Rated to carry compatible Hikvision dome camera models up to 4.5 kg. Always confirm the specific dome model's mass and mounting pattern against this box before including it on a job sheet — it's built as a mounting/cable-management accessory, not a universal fit for every housing.
Used across residential, commercial and industrial CCTV installs wherever protected cable routing and a secure base are required for a dome camera.
Specifications
- Brand
- Hikvision
- Colour
- White
- SKU
- DS-1280ZJ-DM46
- Material
- Aluminium Alloy
- Dimensions
- Ø 120 mm × 37.2 mm (Ø 4.72" × 1.46")
- Weight
- 250 g (0.55 lb.)
Technical Specifications
Frequently Asked Questions
What load can the DS-1280ZJ-DM46 support?
It has a maximum load capacity of up to 4.5 kg, so check the mounted dome camera's weight against this figure before specifying.
Can this junction box be used outdoors?
Yes, it's suitable for both indoor and outdoor CCTV installations.
What is the box made from?
It's constructed from aluminium alloy, giving a durable but lightweight enclosure.
How does cable routing work with this box?
It uses a bottom cable entry point so power and network connections stay concealed within the enclosure.
