Hikvision 16-Channel 2MP – 4MP CCTV Kit — 1 2MP Turret + 11 4MP PTZ Cameras + 14TB Recording
SKU: KIT-IP16-DS7616NIM216-DS2CD1327G2LX12-14TB-1G753Copied!
Built on: Hikvision DS-7616NI-M2/16P + 1× Hikvision DS-2CD1327G2-LUF + 11× Hikvision DS-2DE4425IW-DE. Keeps about 28 days of continuous footage on the included 14TB hard drive.
Available to order
Add to basket or call us — our team will arrange it
How many cameras?
Same recorder and same cameras — just more of them.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a large property or yard — 12 cameras, keeps about 28 days of footage, one network cable per camera carries the picture and the power.
The recorder
Hikvision 16-ch 1U 16 PoE 8K NVR
The box that saves everything and runs the app
The cameras
Hikvision DS-2CD1327G2-LUF 2MP ColorVu PoE IP Turret Camera Mic IP67
What goes on the wall
The cameras× 11
Hikvision DS-2DE4425IW-DE 4MP 25× PTZ Network Camera IR 100m
What goes on the wall
The hard drive
Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM
Where the footage is kept
The cable× 12
Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 16-channel IP (PoE) CCTV kit built on the Hikvision DS-7616NI-M2/16P + 1× Hikvision DS-2CD1327G2-LUF + 11× Hikvision DS-2DE4425IW-DE. 12 cameras at 2MP + 4MP — sized for a larger property or yard. The included 14TB hard drive holds about 28 days of continuous recording — the estimate assumes recording all 12 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 12× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable. In the box: 1× Hikvision 16-ch 1U 16 PoE 8K NVR; 1× Hikvision DS-2CD1327G2-LUF 2MP ColorVu PoE IP Turret Camera Mic IP67; 11× Hikvision DS-2DE4425IW-DE 4MP 25× PTZ Network Camera IR 100m; 1× Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM; 12× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- IP (network)
- Built on
- Hikvision DS-7616NI-M2/16P + 1× Hikvision DS-2CD1327G2-LUF + 11× Hikvision DS-2DE4425IW-DE
- Recorder
- 16-channel Hikvision 16-ch 1U 16 PoE 8K NVR
- Cameras included
- 1× Hikvision DS-2CD1327G2-LUF 2MP ColorVu PoE IP Turret Camera Mic IP67; 11× Hikvision DS-2DE4425IW-DE 4MP 25× PTZ Network Camera IR 100m
- Camera resolution
- 2MP + 4MP
- Storage
- 14TB HDD — about 28 days of footage, recording all 12 cameras continuously at high quality (H.265) — the load is 1× 2MP + 11× 4MP
- Cables & PSU included
- 12× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 16-ch 1U 16 PoE 8K NVR; 1× Hikvision DS-2CD1327G2-LUF 2MP ColorVu PoE IP Turret Camera Mic IP67; 11× Hikvision DS-2DE4425IW-DE 4MP 25× PTZ Network Camera IR 100m; 1× Toshiba MG07ACA14TE 14TB 3.5" SATA III Enterprise HDD 7200RPM; 12× Cat6 Ethernet Cable, Gigabit RJ45 20m, Black - High-Speed LAN Patch Cable
