Product Description
Hikvision DS-7216HGHI-M1 — 16-channel hybrid Turbo HD DVR
A 1U recorder built for sites running mixed analogue and IP cameras on existing coax. It handles HDTVI, AHD, CVI, CVBS and IP inputs on the same unit, so a job with cameras from different generations doesn't need a rip-and-replace.
Key specs
- 16 analogue channels, expandable to up to 18 channels total in hybrid mode by adding IP cameras
- IP channels support resolutions up to 5MP
- Encoding capability up to 1080p Lite @ 15fps
- H.265 Pro+/H.265 Pro/H.265 compression for reduced storage and bandwidth demand
- Max transmission distance 1200m for a 720p HDTVI signal
- Audio in/out via RCA, plus audio over coaxial cable from compatible cameras
- HDMI and VGA outputs, simultaneous, up to 1920×1080
- 10/100 Mbps Ethernet for remote viewing, playback and configuration via Hik-Connect
- One SATA bay, up to 10TB supported
Motion Detection 2.0
Deep-learning based human/vehicle classification is built in, cutting down false triggers from shadows, rain or moving vegetation — useful where alarm-driven workflows can't tolerate noise.
Compatibility note
Also catalogued under DS-7216HGHI-M1-NO-HDD, DS-7216HGHI-M1+NO-HDD and DS-7216HGHI-K1 — same hardware platform, differing only in HDD-bundling variant. Check the exact part number against your BOM before ordering.
Suited to retail, commercial and residential installs needing stable hybrid recording without abandoning existing coaxial runs.
Specifications
- Brand
- Hikvision
- Model
- DS-7216HGHI-M1
- Series
- M-Series
- Channels
- 16-CH
- Max Resolution
- 1080p Lite @ 15fps
- Max Analog Resolution
- 5MP
- IP Channels (Hybrid)
- Up to 18
- Video Compression
- H.265 Pro+, H.265 Pro, H.265, H.264+, H.264
- Recording Resolution
- 1080p Lite, 720p, WD1, VGA, CIF
- Frame Rate
- 15 fps @ 1080p Lite
- Decoding Capability
- 16 Channels
- HDMI/VGA Independent
- Sync
- Max Output Resolution
- 1920 × 1080
- BNC Output
- No
- Max Total Storage
- 10 TB
- eSATA Port
- No
- AcuSense
- No
- DeepinMind / AI
- No
- Human & Vehicle Detection
- Yes
- Face Detection
- No
- Face Recognition
- No
- Perimeter Protection
- No
- Line Crossing
- No
- Intrusion Detection
- No
- False Alarm Filtering
- Yes
Technical Specifications
Frequently Asked Questions
How many channels does the DS-7216HGHI-M1 support?
It has 16 analogue channels and can expand to up to 18 channels total when adding IP cameras in hybrid mode.
What resolution can the IP channels handle?
IP camera inputs on this hybrid mode support resolutions up to 5MP.
What's the maximum cable run for analogue cameras?
Up to 1200m is supported for a 720p HDTVI signal.
How much storage does it take?
It supports one SATA hard drive with up to 10TB capacity.
Are DS-7216HGHI-M1-NO-HDD and DS-7216HGHI-K1 the same unit?
They're listed as the same hardware platform under different part numbers, mainly varying by HDD-bundling — confirm the exact SKU against your requirements before ordering.
