Hikvision & Prolux 32-Channel 2MP – 4MP CCTV Kit — 20 2MP PTZ + 1 4MP Turret Cameras + 2× 6TB Recording
SKU: KIT-HD32-DS7332HQHIK4-DS2AE5225TIAX21-2X6TB-MQSGMCopied!
Built on: Hikvision DS-7332HQHI-K4 + 20× Hikvision DS-2AE5225TI-A-E + 1× Prolux PXC-612C4W-A-POC. Keeps about 25 days of continuous footage on the included 2× 6TB surveillance hard drives (12TB in total).
Available to order
Add to basket or call us — our team will arrange it
How many cameras?
Same recorder and same cameras — just more of them.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
Enough for a commercial site — 21 cameras, keeps about 25 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 5mp 1.5U H.265 DVR
The box that saves everything and runs the app
The cameras× 20
Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera
What goes on the wall
The cameras
Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
What goes on the wall
The hard drive× 2
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply× 2
18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit
One plug that powers the cameras
The cable× 21
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision DS-7332HQHI-K4 + 20× Hikvision DS-2AE5225TI-A-E + 1× Prolux PXC-612C4W-A-POC. 21 cameras at 2MP + 4MP — sized for a commercial site. The included 2× 6TB surveillance hard drives (12TB in total) hold about 25 days of continuous recording — the estimate assumes recording all 21 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 21× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 20× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 1× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 2× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 21× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision DS-7332HQHI-K4 + 20× Hikvision DS-2AE5225TI-A-E + 1× Prolux PXC-612C4W-A-POC
- Recorder
- 32-channel Hikvision 32-ch 5mp 1.5U H.265 DVR
- Cameras included
- 20× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 1× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
- Camera resolution
- 2MP + 4MP
- Storage
- 2× 6TB (12TB total) surveillance HDD — about 25 days of footage, recording all 21 cameras continuously at high quality (H.265) — the load is 20× 2MP + 1× 4MP
- Cables & PSU included
- 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit; 21× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 5mp 1.5U H.265 DVR; 20× Hikvision DS-2AE5225TI-A-E 2MP 25x PTZ Turbo HD Camera; 1× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 2× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 21× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 2× 18 Channel CCTV Power Supply Box 12V DC 30A Distribution Unit
