Product Description
The DS-KH9510-WTE1(B) is Hikvision's Android-based indoor station, specified here as a management terminal rather than a basic hands-free handset. For integrators, the key spec is the platform itself: a full Android OS running behind a 10.1-inch capacitive touchscreen at 1024 × 600, with installation of supported Android applications and third-party software integration alongside the native Hik-Connect app. That gives system designers a route to bespoke control layouts or building-management dashboards on the same hardware used for door entry.
On deployment, the unit operates as the central point for Hikvision intercom and security devices — door stations, connected cameras, and other system components — controlled through a single tablet-style interface. The touchscreen and Hik-Connect combination covers live video, two-way communication with visitors, and device management without needing separate control hardware. Spec this in where a job calls for an Android-capable master station with room for custom app deployment, rather than a fixed-function display.
Key specs
- 10.1" capacitive colour touchscreen, 1024 × 600 resolution
- Built-in Android operating system
- Supports installation of Android applications
- Built-in Hik-Connect application
- Third-party software integration supported
- Designed for Hikvision video intercom systems
- Tablet-style interface for centralised device management
Specifications
- Operating System
- Android 10.1
- Screen Size
- 10.1-inch
- Operation Method
- Capacitive touch screen
- Type
- Colourful IPS
- Max Resolution
- 1024 × 600
- Video Compression
- H.265 ;H.264
- Audio Input
- 1 built-in omnidirectional microphone
- Audio Compression
- G722.1, OPUS, AAC_LC, AAC_LD, G726, G711.U, G711.A
- Audio Output
- 1 built-in loudspeaker
- Audio Compression Bitrate
- 64 Kbps
- Audio Quality
- Noise suppression and echo cancellation
- Volume Adjustment
- Adjustable
- Message Capacity
- 200 captured pictures, 200 alarm records
- Notice Capacity
- 200
- Network Protocol
- TCP/IP, SIP, RTSP
- Wi-Fi
- 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Network Interface
- 1 RJ-45 10/100 Mbps self-adaptive
- TF Card
- Support TF card, up to 128 G
- Lock Control
- 1 relay, Max. 30 VDC 0.3 A, and 1 high/low level relay (3.3 V/0V)
- Installation
- Surface mounting
- Operating Temperature
- -10 °C to 50 °C (14 °F to 122 °F)
- Operating Humidity
- 10% to 90% (no-condensing)
- Dimensions
- 254 mm × 166 mm × 26.65 mm (10.0" × 6.54" × 1.05")
- Power Supply
- 12 VDC, 1 A, IEEE802.3af, standard PoE
- Application Environment
- Indoor
Technical Specifications
Frequently Asked Questions
Can this station run apps beyond the standard intercom software?
Yes — it runs a built-in Android OS and supports installation of supported Android applications in addition to the native Hik-Connect app.
Does it support third-party integration?
Yes, the SOURCE confirms support for third-party software integration alongside Hikvision's own Hik-Connect platform.
What's the screen spec?
A 10.1-inch capacitive colour touchscreen with 1024 × 600 resolution.
What can be managed from the Hik-Connect interface on this unit?
Hik-Connect on this station allows interaction with door stations, live video viewing, visitor communication, and management of connected devices from the single indoor terminal.
