Product Description
DS-2CE70K0T-PTLTS delivers 2960 × 1665 (3K) resolution over standard coax, with audio over coax and a built-in mic/speaker for two-way monitoring. For installers upgrading legacy analogue runs, this is a straight swap-in with no need for new cabling.
Key specs
- Resolution: 2960 × 1665 (3K), fixed 2.8 mm lens
- Signal formats: HD-TVI, AHD, CVI, CVBS — drops into modern or legacy analogue systems
- Illumination: up to 20 m white light, 25 m IR, with Smart-Hybrid Light switching between the two
- Audio: built-in mic and speaker, two-way audio carried over coax to compatible Hikvision DVRs
- Housing: IP67-rated turret, adjustable mount for ceiling or wall
Why it matters on the job
Audio-over-coax removes the need for a separate audio cable run — mic and speaker signal rides the same coax as video, provided the DVR at the head end supports audio-over-coax on that channel. Confirm this before quoting a multi-camera audio install.
ColorVu-style white-light illumination keeps the image in colour after dark rather than dropping to mono IR, which matters for identification tasks at entrances and corridors. The 25 m IR range gives a fallback for wider perimeter coverage where white light isn't wanted.
Format flexibility (TVI/AHD/CVI/CVBS) means this turret works as a drop-in replacement across mixed-generation analogue estates without swapping the recorder — useful for phased upgrades where the DVR is staying put.
The 2.8 mm fixed lens suits typical entrance, corridor and wall-mount coverage; no varifocal adjustment is available on this model.
Specifications
- Model
- DS-2CE70K0T-PTLTS
- Camera Type
- Analog Camera
- Camera Style
- PT Turret
- Housing Material
- Plastic
- IR Distance
- 25m
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- ICR
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Two-Way Audio
- Yes
- Connection Type
- Analogue
- SD Card Slot
- No
- ONVIF Support
- No
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
Technical Specifications
Frequently Asked Questions
Does this camera need a special DVR for audio over coax?
The built-in mic and speaker send audio over the same coax cable, but the DVR channel must support Hikvision's audio-over-coax function to record and play it back.
Can this replace an older analogue camera without rewiring?
Yes — it supports HD-TVI, AHD, CVI and CVBS signal formats, so it can generally be fitted onto existing coax runs across older and newer analogue systems.
What lens options does it come with?
It ships with a fixed 2.8 mm lens only; there is no varifocal or zoom option on this model.
Is it suitable for outdoor use?
The housing is IP67-rated for dust and water ingress protection, and it's designed for wall or ceiling mounting at entrances, corridors or perimeters.
