Product Description
What the DS-2CE17K0T-LXTS is
A 3K HD-TVI bullet camera for analogue systems that need integrated audio and active deterrence, not just recording.
Key specs
- Resolution: 2960 × 1665 (3K) — sharper detail than standard 1080p when paired with a compatible Hikvision DVR
- Lens: 2.8 mm fixed focal, giving a stable, predictable field of view with no on-site adjustment needed
- Illumination: up to 40 m white light and up to 40 m IR range, with Smart-Hybrid Light switching between the two for flexible night-time coverage
- Colour at night: ColorVu tech uses built-in white light rather than relying purely on IR, keeping colour detail visible after dark
- Audio: built-in mic and speaker, plus audio-over-coax so audio and video travel on the same cable run to compatible recorders — no extra cabling
- Deterrence: active strobe light and audio alarm can be triggered for on-site warning
- Housing: IP67-rated, suitable for exposed outdoor mounting
Format compatibility
Outputs HD-TVI, AHD, CVI and CVBS, so it drops into most analogue DVR platforms without a full system swap — useful when upgrading an existing multi-brand install.
Where it fits
Fixed 2.8 mm coverage and two-way audio suit entrances, driveways, perimeter runs and building exteriors where an installer needs both identification-grade imaging and a way to challenge or warn on-site, without adding a separate intercom.
Also listed under part number DS-2CE17K0T-LXTS-2.8mm — same camera, same specification.
Specifications
- Camera Type
- Analog Camera
- Camera Style
- Bullet
- IR Distance
- 40m
- ColorVu
- Yes
- White Light
- Yes
- Day/Night Mode
- ICR
- Built-in Microphone
- Yes
- Built-in Speaker
- Yes
- Two-Way Audio
- Yes
- Connection Type
- Analogue
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
- Max Resolution
- 2960 (H) × 1665 (V)
- Image Sensor
- 3K CMOS
- Supplement Light Type
- Smart,IR,White Light
- Supplement Light Range
- IR: Up to 40 m,White Light: Up to 40 m
- Noise Reduction
- 2D DNR
- White Balance
- Auto, Manua
- Alarm
- Flashing Light Alarm (Red & Blue)
- Material
- Main body: Metal; Enclosure: Plastic
- Dimensions
- 211 mm × 83.5 mm × 80.7 mm (8.31" × 3.29" × 3.18")
- Protection
- IP67
Technical Specifications
Frequently Asked Questions
What resolution does the DS-2CE17K0T-LXTS record at?
It delivers a maximum resolution of 2960 × 1665 (3K) when connected to a compatible Hikvision DVR.
Does this camera need an infrared illuminator for night imaging?
No — it uses Smart-Hybrid Light, combining built-in white light with IR, giving up to 40 m range on each for ColorVu night-time colour imaging.
Can it send audio without running a separate cable?
Yes, the built-in microphone supports audio-over-coax, so audio and video travel over the same cable to a compatible recorder.
Is the DS-2CE17K0T-LXTS-2.8mm a different product?
No, it's the same camera listed under an alternate part number with the same 2.8 mm fixed lens and specification.
What analogue formats does it support?
It outputs HD-TVI, AHD, CVI and CVBS, allowing it to integrate with a wide range of analogue DVR platforms.
