Product Description
A DC 2.1mm female power connector with a push-button terminal, built for CCTV and 12V power wiring on site.
What it does
The jack accepts standard 5.5mm x 2.1mm DC male plugs, matching the barrel size found on common 12V CCTV power supplies and camera leads. The push terminal secures bare conductors without a screwdriver or solder, so mid-run joins and terminations go in faster on multi-camera first fix.
Where it's used
- CCTV power wiring between supply units and cameras
- Integration into power distribution boxes
- LED systems using the same 5.5mm x 2.1mm barrel
Build and fit
It's a compact inline adapter, so it fits inside junction boxes, camera housings and other confined equipment enclosures where a bulkier connector won't sit.
Compatibility note
Confirm the barrel size on your existing plugs before specifying this part — it's built for the 5.5mm x 2.1mm standard only, and other DC barrel formats will not seat correctly.
Termination is tool-free: strip the conductor, press the terminal, insert, release. No crimping, soldering or screw terminals required, which keeps installation consistent across multiple runs on a job.
Specifications
- Voltage
- 12V
- Colour
- Red
Technical Specifications
Frequently Asked Questions
What plug does this connector accept?
Standard 5.5mm x 2.1mm DC male plugs, the common barrel size used on 12V CCTV power supplies and camera leads.
Do I need tools to terminate a wire?
No — the push-button terminal secures bare conductors without a screwdriver or solder.
Where can this be fitted?
Its compact inline design fits junction boxes, camera housings and other confined equipment enclosures.
Will it work with other DC barrel sizes?
No — check your existing plugs match 5.5mm x 2.1mm first, as other DC barrel formats will not seat correctly.
