Product Description
Spec sheet, straight through: 2m black CAT6 U/UTP patch lead terminated RJ45 male to RJ45 male, gold-plated copper alloy pins, polycarbonate housings, PVC jacket.
Key specs
- Category: Cat.6, U/UTP (unshielded twisted pair)
- Length: 2m (4.92ft)
- Conductor: 24AWG copper, U/UTP construction
- Bandwidth: 250MHz supported
- Attenuation: 32.8dB/100m @250MHz
- Jacket: PVC, 5.8mm diameter
- Minimum bend radius: 69mm
- Operating range: -10°C to 60°C; storage -20°C to 75°C
- Connector body: 11.6×22.8×8.3mm, polycarbonate
On a job this is the short-run patch cable — router-to-switch, NVR-to-camera drop where the CCTV run is already close, or PC/PS4 uplink. The U/UTP build means no drain wire or shield termination to manage, which keeps rack dressing quick on short jumps.
Backward-compatible with Cat.5e infrastructure per the listing, so it drops into mixed-generation cabling without a media converter. Gold-plated pins on copper alloy contacts are the only plating spec given — no shielding is listed, so treat this as an unshielded run and route accordingly where EMI sources are present on site.
Stock code on this listing: RJ45-NETWORK-CABLE-CAT6-2M-BLACK.
Specifications
- Colour
- Black
- Connector Type
- RJ45
Technical Specifications
Frequently Asked Questions
Is this cable shielded?
No shielding is specified for this cable — it's a U/UTP (unshielded twisted pair) construction.
What bandwidth does it support?
250MHz, with attenuation rated at 32.8dB/100m at that frequency.
Will it work with Cat.5e equipment?
Yes, it's listed as CAT6/CAT5e compatible, so it can be used in mixed-generation network runs.
What's the minimum bend radius?
69mm (2.72in) is the minimum band radius given for this cable.
