Texecom AKC-0006 Capture Q20 Quad PIR Motion Detector Grade 2 Black

Detector type and grading

Wired Quad PIR volumetric detector, EN50131-2-2 Grade 2 compliant — the standard grading for residential and light commercial intruder panels. MPN AKC-0006, Capture Q20 series, black housing.

Key specs

• Detection range: up to 20m
• Coverage angle: 90°
• Sensor type: quad element pyro (four sensing elements combined for improved discrimination against false triggers)
• Temperature compensation: digital, auto-adjusts sensitivity as ambient temperature shifts
• Pet immunity: optional PetWise mode
• Mounting height: approx. 1.5m–3m, indoor use only

Specification notes for installers

Grade 2 rating means the AKC-0006 pairs correctly with Grade 2 (or Grade 2/3) control panels where the install spec calls for Grade 2 detection throughout — mixing grades on a single panel typically drops the system's overall compliance grade to the lowest-rated device, so check panel and detector grading match before committing to a schedule.

The quad pyro element and digital temperature compensation are aimed at reducing nuisance alarms from environmental drift (draughts, heating cycles, direct sunlight patches) without derating the 20m/90° coverage envelope. PetWise mode is switchable, so the same SKU covers both pet-free commercial spaces and domestic rooms with small animals present.

Wall mount only, indoor rated — no external/outdoor coverage figures are specified for this unit, so treat internal hallways, rooms and protected areas as the intended zones.
