Product Description
The SPL-4 is a 4-port lever connector for terminating CCTV power and low-voltage wiring. It handles 12V DC and 24V DC distribution, covering the voltage ranges installers deal with when splitting a PSU feed to cameras and auxiliary devices.
Key specs
- 4 independent ports per connector body
- Rated for 12V DC and 24V DC power distribution
- Tool-free lever clamp termination — no screw terminals or crimping
- Accepts solid and stranded copper conductors
- Compact housing sized for CCTV junction boxes and back boxes
Where it's used
On a CCTV job this connector sits inside a junction box, camera back box, or enclosure to split a single incoming feed across multiple conductors. It's suited to distributing power from a centralised supply to cameras and auxiliary low-voltage devices such as alarm circuits or LED runs.
Termination
Each port opens with a lever, takes the conductor, and closes to clamp it — no tools required. This works for both solid-core and stranded copper, so it covers the conductor types typically found in CCTV power cable and alarm/control wiring on site.
Fit
The compact insulated body is built for confined spaces — network cabinets, camera back boxes, and electrical enclosures — where a full terminal strip won't fit.
Specifications
- Voltage
- 12V
- Colour
- Grey
Technical Specifications
Frequently Asked Questions
What voltages does the SPL-4 support?
It's rated for 12V DC and 24V DC, covering the standard camera power distribution ranges from a centralised PSU.
How many ports does it have?
Four independent connection ports per unit.
Does it need tools to terminate wires?
No — it uses a tool-free lever clamp, so conductors are inserted and secured without screwdrivers or crimpers.
What conductor types does it accept?
Both solid and stranded copper conductors, as used in CCTV power, alarm, and control cabling.
