Prolux & Hikvision 32-Channel 2MP – 4MP CCTV Kit — 9 2MP Dome + 9 4MP Turret Cameras + 3× 6TB Recording
SKU: KIT-HD32-IDS7332HUHIM-HDT2MPN20W28X18-3X6TB-7U0TVCopied!
Built on: Hikvision iDS-7332HUHI-M4/S + 9× HDT-2MP-N20W-2.8MM + 9× Prolux PXC-612C4W-A-POC. Keeps about 30 days of continuous footage on the included 3× 6TB surveillance hard drives (18TB in total).
Available to order
Add to basket or call us — our team will arrange it
How many cameras?
Same recorder and same cameras — just more of them.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Every part in this kit and how many of each you get. Tap a part to see its full specification.
Enough for a commercial site — 18 cameras, keeps about 30 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras× 9
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The cameras× 9
Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
What goes on the wall
The hard drive× 3
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
One plug that powers the cameras
The cable× 18
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 32-channel HD-over-coax CCTV kit built on the Hikvision iDS-7332HUHI-M4/S + 9× HDT-2MP-N20W-2.8MM + 9× Prolux PXC-612C4W-A-POC. 18 cameras at 2MP + 4MP — sized for a commercial site. The included 3× 6TB surveillance hard drives (18TB in total) hold about 30 days of continuous recording — the estimate assumes recording all 18 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when they fill. Power and cabling are covered: 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR; 9× 2MP HD 4in1 Dome Camera (2.8mm/ White); 9× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 3× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision iDS-7332HUHI-M4/S + 9× HDT-2MP-N20W-2.8MM + 9× Prolux PXC-612C4W-A-POC
- Recorder
- 32-channel Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR
- Cameras included
- 9× 2MP HD 4in1 Dome Camera (2.8mm/ White); 9× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible
- Camera resolution
- 2MP + 4MP
- Storage
- 3× 6TB (18TB total) surveillance HDD — about 30 days of footage, recording all 18 cameras continuously at high quality (H.265) — the load is 9× 2MP + 9× 4MP
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 32-ch 8MP 1.5U H.265 AcuSense DVR; 9× 2MP HD 4in1 Dome Camera (2.8mm/ White); 9× Prolux 4MP PoC Audio Eyeball Camera 2.8mm 50m IR Hikvision Compatible; 3× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 18× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 15A Fused Distribution Unit
