Product Description
The Dahua PFA130-E-G Waterproof Junction Box is a round aluminium alloy enclosure with a white finish, made for compatible CCTV cameras. It mounts the camera and closes over the cable connections at the fixing point, so the termination is out of sight and shielded from environmental exposure.
Data for the job sheet
- Cable entry: G3/4 thread
- Ingress protection: IP66 (dust and powerful water jets)
- Maximum load: 3 kg
- Footprint: 124.3 mm diameter, 41 mm deep
- Operating temperature: −40°C to +60°C
- Construction: aluminium alloy, white finish
Before you fix it
- Match the camera model against Dahua's accessory selection guide.
- Check the camera's weight sits within the 3 kg limit.
- G3/4 is a pipe-type thread, so any gland or conduit adaptor going into the entry has to carry the same thread.
- Allow for the 41 mm depth where the camera sits close to a soffit, return or neighbouring fitting.
The IP66 rating and the −40°C to +60°C range mean the same box can be specified for indoor and outdoor surveillance positions on one site.
Specifications
- NVR Compatibility
- Hikvision, HiLook, Annke & any Hikvision-made OEM. Also compatible with any other NVR that supports ONVIF.
- Casing Material
- Aluminum alloy
- Product Dimensions
- Φ124.3 mm × 41.0 mm (Φ4.89" × 1.61")
- Appearance Color
- White
- Packaging Dimensions
- 146 mm × 65 mm × 147 mm (5.75" × 2.56" × 5.79") (L × W × H)
Frequently Asked Questions
What is the cable entry thread on the PFA130-E-G?
It has a G3/4 threaded cable entry, so any gland or conduit fitting must match that thread.
Can it be used outdoors?
Yes. It is IP66 rated for protection against dust and powerful water jets and suits both indoor and outdoor surveillance installations.
What is the maximum camera weight?
The maximum load is 3 kg.
How do I confirm my camera is compatible?
Check the camera model against Dahua's accessory selection guide before installation.
