Product Description
IP55-rated junction box for cable joints on CCTV, network and electrical runs. Overall enclosure dimensions are 118 × 98 × 50mm — allow for wall fixings and cable entry when checking clearance on site.
Key specs
- IP rating: IP55 — protected against dust ingress and water spray from any direction
- Overall dimensions: 118 × 98 × 50mm (enclosure footprint, not internal cavity)
- Material: durable grey plastic
- Cover: removable, for access during install and maintenance
- Mounting: wall-mount design; also suited to ceiling or surface fixing near cameras, access control or network equipment
On the job
Use it to house a mid-run cable joint before conduit entry, to protect a connector or small module such as a balun sited outdoors, or to keep a network/electrical junction enclosed and tidy. The IP55 rating means it holds up on an external wall, in a loft, or in a garage installation where cables need protecting from moisture and debris but full immersion protection isn't required.
Fit check before ordering
The 118 × 98 × 50mm figure is the outer enclosure size used for mounting and clearance planning — it is not a spec for usable internal space, so confirm connector bulk and cable slack will sit comfortably inside before specifying it for a tight termination.
Suitable for both indoor and outdoor CCTV, networking and general electrical installations requiring a compact, enclosed connection point.
Specifications
- IP Rating
- IP55
- Dimensions
- 118 × 98 × 50 mm
- Colour
- Grey
Frequently Asked Questions
What do the 118 × 98 × 50mm dimensions refer to?
That's the overall enclosure/installation footprint, not the internal usable cavity — check connector and cable slack against this before specifying for tight terminations.
What does the IP55 rating protect against?
IP55 means the enclosure is protected against dust ingress and against water spray from any direction, suiting both indoor and outdoor installation.
Can this box be used for CCTV camera cable joints?
Yes — it's designed for housing cable joints, connectors or small modules such as baluns on CCTV, networking and electrical wiring runs.
Is the cover removable for maintenance access?
Yes, the enclosure has a removable cover for access during installation and maintenance.
