Hikvision 8-Channel 5MP CCTV Kit — 5 Bullet + 2 White Turret Cameras + 6TB Recording
SKU: KIT-HD8-IDS7208HQHIM-DS2CE12KF3TPX07-6TB-11HVKCopied!
Built on: Hikvision IDS-7208HQHI-M1/XT + 5× Hikvision DS-2CE12KF3T-PIRXO + 2× Hikvision DS-2CE78H0T-IT3FS. Keeps about 19 days of continuous footage on the included 6TB surveillance hard drive.
Discontinued
This product has been discontinued
How many cameras?
Same recorder and same cameras — just more of them.
Which camera styles?
The same kit, split differently between camera styles.
How to buy this item: add it to your basket and send us a pricing request, or contact our sales team directly.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 7 cameras, keeps about 19 days of footage, it reuses the round coax cable an older system left behind.
The recorder
Hikvision 8-ch 5MP 1U H.265 AcuSense DVR
The box that saves everything and runs the app
The cameras× 5
HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera
What goes on the wall
The cameras× 2
Hikvision 5 MP Audio Fixed Turret Camera
What goes on the wall
The hard drive
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply
12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
One plug that powers the cameras
The cable× 7
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the Hikvision IDS-7208HQHI-M1/XT + 5× Hikvision DS-2CE12KF3T-PIRXO + 2× Hikvision DS-2CE78H0T-IT3FS. 7 cameras at 5MP — sized for a shop or small office. The included 6TB surveillance hard drive holds about 19 days of continuous recording — the estimate assumes recording all 7 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× Hikvision 8-ch 5MP 1U H.265 AcuSense DVR; 5× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 2× Hikvision 5 MP Audio Fixed Turret Camera; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed. Free Hik-Connect app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Hikvision IDS-7208HQHI-M1/XT + 5× Hikvision DS-2CE12KF3T-PIRXO + 2× Hikvision DS-2CE78H0T-IT3FS
- Recorder
- 8-channel Hikvision 8-ch 5MP 1U H.265 AcuSense DVR
- Cameras included
- 5× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 2× Hikvision 5 MP Audio Fixed Turret Camera
- Camera resolution
- 5MP
- Storage
- 6TB surveillance HDD — about 19 days of footage, recording all 7 cameras continuously at high quality (H.265)
- Cables & PSU included
- 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free Hik-Connect app (iOS / Android) for live view and playback
- What's in the box
- 1× Hikvision 8-ch 5MP 1U H.265 AcuSense DVR; 5× HIKVISION 3K ColorVu PIR Siren Fixed Bullet Camera; 2× Hikvision 5 MP Audio Fixed Turret Camera; 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 7× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 12V 5A Power Supply with Built-in 8-Way Splitter – UK Plug, Boxed
