Hikvision & Dahua 8-Channel 2MP CCTV Kit — 1 PTZ + 7 Dome Cameras + 6TB Recording
SKU: KIT-HD8-XVR3108AD4K-DS2AE4225TAHX08-6TB-M9V9UCopied!
Built on: Dahua XVR-3108AD-4K + 1× Hikvision DS-2AE4225T-A + 7× HDT-2MP-N20W-2.8MM. Keeps about 34 days of continuous footage on the included 6TB surveillance hard drive.
In Stock
Ready to ship • 15 available
How many cameras?
Same recorder and same cameras — just more of them.
How to buy: add to your basket, then check out securely by card — or contact Sales for larger quantities.
What's in the box
Everything you need is here — nothing to order separately, and nothing to work out. Each part is a real product you could buy on its own, and we have checked them against each other before boxing them.
Enough for a shop or small business — 8 cameras, keeps about 34 days of footage, it reuses the round coax cable an older system left behind.
The recorder
XVR-3108AD 8CH 4K Hybrid CCTV DVR 8MP XVR Powered By Dahua
The box that saves everything and runs the app
The cameras
Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome
What goes on the wall
The cameras× 7
2MP HD 4in1 Dome Camera (2.8mm/ White)
What goes on the wall
The hard drive
Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in
Where the footage is kept
The power supply
18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
One plug that powers the cameras
The cable× 8
RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
Runs from each camera back to the recorder
Want different cameras, a bigger drive or longer cable runs? Open this exact kit in the builder and change any part — everything is re-checked against the rest as you go, so you cannot end up with parts that do not work together.
Product Description
A complete 8-channel HD-over-coax CCTV kit built on the Dahua XVR-3108AD-4K + 1× Hikvision DS-2AE4225T-A + 7× HDT-2MP-N20W-2.8MM. 8 cameras at 2MP — sized for a shop or small office. The included 6TB surveillance hard drive holds about 34 days of continuous recording — the estimate assumes recording all 8 cameras continuously at high quality (H.265), and the recorder writes over the oldest footage when the drive fills. Power and cabling are covered: 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR, 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Nothing else is needed to start recording: recorder, cameras, storage, power and cabling are all in the box. In the box: 1× XVR-3108AD 8CH 4K Hybrid CCTV DVR 8MP XVR Powered By Dahua; 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 7× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit. Free DMSS app (iOS / Android) for live view and playback.
Specifications
- System type
- Analog (HD over coax)
- Built on
- Dahua XVR-3108AD-4K + 1× Hikvision DS-2AE4225T-A + 7× HDT-2MP-N20W-2.8MM
- Recorder
- 8-channel XVR-3108AD 8CH 4K Hybrid CCTV DVR 8MP XVR Powered By Dahua
- Cameras included
- 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 7× 2MP HD 4in1 Dome Camera (2.8mm/ White)
- Camera resolution
- 2MP
- Storage
- 6TB surveillance HDD — about 34 days of footage, recording all 8 cameras continuously at high quality (H.265)
- Cables & PSU included
- 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR
- What you need to add
- Nothing — recorder, cameras, surveillance hard drive, power and cabling are all included
- Mobile app
- Free DMSS app (iOS / Android) for live view and playback
- What's in the box
- 1× XVR-3108AD 8CH 4K Hybrid CCTV DVR 8MP XVR Powered By Dahua; 1× Hikvision 4-inch 2 MP 25X Powered by DarkFighter Analog Speed Dome; 7× 2MP HD 4in1 Dome Camera (2.8mm/ White); 1× Seagate SkyHawk 6TB Surveillance HDD SATA 6Gb/s 3.5in; 8× RG59 CCTV Cable 20m BNC Video with DC Power Shotgun Lead for Camera to DVR; 1× 18 Channel CCTV Power Supply Box 12V DC 20A Fused Distribution Unit
