Product Description
Spec sheet
9U of standard 19-inch rack space in a wall-mounted steel enclosure — sized for patch panels, switches and small NVRs where a floor-standing rack isn't an option.
- Capacity: 9U, standard 19-inch rack width — takes off-the-shelf patch panels, switches and telecoms hardware
- External dimensions: 600mm (W) × 300mm (D) × 500mm (H)
- Construction: steel body, black powder-coated finish
- Access: lockable front door for controlled access during maintenance
- Cooling: ventilated panels for passive airflow around active devices
- Fixing: wall-mounted, suited to comms cupboards, offices and CCTV control points
Depth note
300mm is the external depth of the cabinet, so usable internal clearance for mounted equipment is less than 300mm once the steel body and door are accounted for. Check the depth of your patch panel or switch, including connector and cable bend clearance, against this before specifying it for deeper equipment.
Where it fits
This is a shallow-depth wall cabinet rather than a full server enclosure. It's aimed at installs where rack gear needs to be organised and secured but floor space or depth is limited — a common requirement in CCTV control points and small structured cabling setups feeding IP cameras or NVRs. The 19-inch rack format means it accepts standard patch panels, switches and routers without adapters.
Specifications
- Width
- 31cm
- Depth
- 30cm
- Height
- 48cm
Frequently Asked Questions
What are the external dimensions of this cabinet?
600mm wide, 300mm deep and approximately 500mm high, giving 9U of standard 19-inch rack space.
Is the 300mm depth the internal clearance for equipment?
No — 300mm is the external depth. Internal clearance for mounted equipment is less once the steel body and door are accounted for, so check your equipment's depth before ordering.
Does it take standard 19-inch patch panels and switches?
Yes, it's built to the standard 19-inch rack format used for patch panels, switches, routers and other telecoms devices.
Can this be locked for security?
Yes, it has a lockable front door that provides controlled access while still allowing maintenance when needed.
